Westerschelde 26 April 2015 |
 |
| Westerschelde 26/04/15 |
|
Name |
OOCL RAUMA |
|
Previous names |
2009 - 06.2012 Elysee |
|
Type |
Cellular containership - Open top Confeeder |
|
IMO-number |
9462794 |
|
Call sign |
PBWS |
|
Flag |
The Netherlands |
|
Port of registry |
Harlingen |
|
GT |
17.488 t |
|
DWT |
Summer: 17.892 t |
|
NT |
8.125 t |
|
Number of 20ft containers |
On deck: 288 Open hold: 1.097 Closed hold: 40 Total: 1.425 |
|
Number of 40ft containers |
On deck: 98 + 91 TEU Open hold: 538 + 21 TEU Closed hold: 18 - 4 TEU Total: 654 + 117 TEU |
|
Container capacity 14t |
1.030 |
|
Reefer capacity |
On deck: 58 Open hold: 243 Closed hold: - Total: 301 |
|
Length |
168,11 m overall 155,40 m between perpendiculars |
|
Breadth |
27,04 m extreme 26,80 m moulded |
|
Draught |
9,60 m |
|
Depth |
14,00 m |
|
Speed |
Max.: 19,7 knots |
|
Built |
2009 |
|
Keel laid |
27.06.2007 |
|
Launch date |
11.07.2009 |
|
Date of completion |
05.11.2009 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. |
|
Yard number |
1294 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x MAN B&W 8L58/64 CD - 4 stroke single acting 8 cylinder580 x 640 mm diesel engine 11.200 kW at 121,5 rpm Manufacturer: MAN B&W Diesel AG, Augsburg - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Thermal oil heater, oil fired 1x Thermal oil heater, exhaust heated |
|
Shaft generator |
1x 2.288 kW |
|
Generators |
3x Caterpillar 3508 Main diesel generatorsets each 920 kW |
|
Emergency generator |
1x MAN D2866TE diesel generatorset 180 kW |
|
Bow thruster |
900 kW, forward 750 kW, aft |
|
Number of holds |
3 |
|
Number of hatches |
1x With one flap type hatch cover |
|
Tank capacities |
Ballast: 6.876,1 m³ Heavy fuel oil: 1.380 t fresh water: 138 t Diesel oil: 260 t |
|
Anchor equipment |
Length: 608,50 m Diameter: 64 mm |
|
Cargo gear |
Gearless |
|
Manager |
JR Ship Management B.V. |
|
Operator |
OOCL - Orient Overseas Container Line |
|
Registered owner |
MS "ELYSEE" Bewaarder B.V. |
|
Previous names & owners |
2009 - 06.2012 Elysee - Elysee Shipping B.V., Harlingen - The Netherlands 06.2012 - 12.2012 OOCL Rauma - Elysee Shipping B.V., Harlingen - The Netherlands |
|
Latest data adjustment |
13 October 2016 |
