Westerschelde 09 April 2020 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 30/04/15 | Westerschelde 30/04/15 | Westerschelde 08/04/20 | Westerschelde 11/06/20 | Westerschelde 21/06/19 | Westerschelde 10/06/20 | |||||
 |
||||||||||
| Westerschelde 09/09/20 | ||||||||||
|
Name |
OOCL MONTREAL |
|
Type |
Cellular containership - Panamax |
|
IMO-number |
9253739 |
|
Call sign |
VRYO3 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
55.994 |
|
DWT |
Summer: 47.840 t |
|
NT |
22.426 |
|
Number of 20ft containers |
In hold: 2.332 On deck: 2.070 Total: 4.402 |
|
Container capacity 14t |
3.200 |
|
Reefer capacity |
330 |
|
Length |
293,99 m overall 281,00 m between perpendiculars |
|
Breadth |
30,32 m extreme |
|
Draught |
10,78 m |
|
Freeboard |
3.172 mm |
|
Depth |
24,60 m |
|
Speed |
22,0 knots Max.: 24,0 knots |
|
Built |
2003 |
|
Keel laid |
30/12/2002 |
|
Launch date |
15/03/2003 |
|
Date of completion |
16/05/2003 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co., Ltd. 1, Aju-dong, Geoje-si 656-714 Geoje-si Republic of Korea |
|
Yard number |
4090 |
|
Hull material |
Steel |
|
Bulkheads |
Transverse: 9 |
|
Number of decks |
1 |
|
Main engine |
1x Doosan/MAN-B&W 8K90MC-C - 2 stroke single acting 8 cylinder 900 x 2.300 combustion engine 37.265 kW / 50.679 bhp at 105,0 rpm Builder: Doosan Engine Co Ltd - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 105 rpm Builder: Hyundai Heavy Ind. Co. Ltd. |
|
Boilers |
1x Auxiliary boiler, composite 1x Auxiliary boiler, oil/gas fired Builder: KangRim Industries. Co., Ltd. |
|
Generators |
3x MAN 8L27/38 - 4 stroke 8 cylinder 270 x 380 mm combustion engines each 2.300 kW connected with generators 2.200 kW / 440 Volt 60 Hz Builder: MAN B&W Diesel AG |
|
Emergency generator |
1x MAN D2866LE/LXE diesel generatorset Builder: MAN Nutzfahrzeuge AG |
|
Bow thruster |
1x Tunnel thruster 1.850 kW / 2.515 bhp, forward 1x Tunnel thruster 1.850 kW / 2.515 bhp, aft |
|
Hatchways |
14x Hatches dimension 12,60 x 28,07 m each 1x Hatch dimension 12,60 x 23,09 m 1x Hatch dimension 12,60 x 13,01 m 1x Hatch dimension 12,60 x 8,37 m |
|
Ballast capacity |
21.811,5 m³ |
|
Anchor equipment |
Length: 357,5 m Diameter: 87 mm |
|
Cargo gear |
Gearless |
|
Crew size |
22 |
|
ISM & commercial manager |
Orient Overseas Container Line Ltd.(OOCL) 31st Floor, Harbour Centre, 25, Harbour Road Wan Chai Hong Kong - China |
|
Previous managers |
2003 - 2003 OOCL Ltd. SHD/SEP Coordinator |
|
Operator |
OOCL - Orient Overseas Container Line |
|
Registered owner |
Newcontainer 4090 Shipping Inc. c/o Orient Overseas Container Line Ltd (OOCL) 31st Floor, Harbour Centre, 25, Harbour Road, Wan Chai, Hong Kong China |
|
Previous owners |
2003 - 2015 XI River B.V., Amsterdam, 1083 HK - The Netherlands 2015 Xiang L5 HK International Ship Lease Co., Limited |
|
Latest data adjustment |
17 June 2025 |
