| Westerschelde 16 April 2016 |
 |
 |
 |
 |
 |
||||
| WS 16/04/16 | Zeebrugge 07/07/14 | Zeebrugge 07/07/14 | Zeebrugge 07/07/14 | Zeebrugge 10/12/13 | ||||
|
Name |
PAGE AKIA |
|
Previous names |
Launch as: Helga 2003 - 09/2013 Helgaland |
|
Type |
Cellular containership |
|
IMO-number |
9277395 |
|
Call sign |
DCOO2 |
|
Flag |
Germany |
|
Port of registry |
Hamburg |
|
Previous flag |
2003 - 2013 United Kingdom, London - Call sign: VQTM5 |
|
GT |
7.519 t |
|
DWT |
Summer: 8.627 t |
|
NT |
3.570 t |
|
Number of 20ft containers |
828 |
|
Container capacity 14t |
507 |
|
Reefer capacity |
150 (50 under deck) |
|
Length |
137,50 m overall 126,42 m registered |
|
Breadth |
21,30 m registered |
|
Draught |
7,46 m |
|
Forecastle |
37,57 m |
|
Poop |
27,19 m |
|
Depth |
9,36 m moulded |
|
Speed |
Max.: 19,3 knots Service: 18,5 knots |
|
Built |
2003 |
|
Keel laid |
10/06/2002 |
|
Launch date |
27/01/2003 |
|
Date of completion |
22/05/2003 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. Neuenfelder Fährdeich 88 21129 Hamburg Federal Republic of Germany |
|
Yard number |
1160 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
7 |
|
Main engine |
1x MaK 9M43 - 4 stroke single acting 9 cylinder 430 x 610 mm combustion engine 7.950 kW / 11.424 bhp at 500 rpm Year of manufacture: 2003 Manufacturer: Caterpillar Motoren GmbH & Co. KG Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 137 rpm |
|
Boilers |
1x Thermal oil heater, oil fired - 10,0 bar Heating Surface: 51,7 m² 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating Surface: 212,0 m² Year of manufacture: 2002 Manufacturer: PWT Prozess-Wärmeträgertechnik GmbH Justus-von-Liebig-Ring 4-6 25451 Quickborn Federal Republic of German |
|
Electric installations |
1x Plant 380/220 V - 1.250 kVA 1x Plant 380 V- 1.625 kVA 1x Plant 380 V - 290 kVA 1x Plant 24 V - 140 Ah 1x Plant 400 V - 16 kVA |
|
Shaft generator |
1x 1.625 kVA/ 1.220 kW |
|
Generators |
2x Caterpillar 3412 DITA main diesel generatorsets each 625 kVA / 500 kW |
|
Emergency generator |
1x Caterpillar 3406 DITA diesel generatorset 290 kVA |
|
Batteries |
2x Batteries for start emergency engine each 140 Ah 1x Battery for start main engine 16 kVA |
|
Compressed air receivers |
2x Receivers each750 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster BRUNVOLL - 750 kW, forward |
|
Tank capacities |
Fuel oil: 778 m³ Water ballast: 3.735,3 m³ |
|
Anchor equipment |
3x Anchors weight each 4.890 kg Chain length: 550,00 m Diameter: 54mm |
|
Cargo gear |
Gearless |
|
Crew |
11 |
|
Crew size |
19 |
|
Manager |
Este-Shipmanagement GbR Königreicher Str. 114A 21635 Jork Germany |
|
Previous managers |
|
|
Owner |
H.H. Shipping GmbH & Co. KG Königreicher Str. 114A 21635 Jork Federal Republic of Germany |
|
Registered owner |
MS "PAGE AKIA" Schifffahrtsgesellschaft mbH & Co. KG Mönckebergstr. 22 20095 Hamburg Federal Republic of Germany |
|
Previous owners |
05/2003 - 09/2013 Helga G.m.b.H. & Co KG, London - United Kingdom |
|
Renamed |
09/2017 Helga The Netherlands, Heerenveen - Call sign: PBFY Owner: Scheepvaartonderneming Helga B.V., Heerenveen - The Netherlands Manager: Holwerda Shipmanagement B.V., Heerenveen - The Netherlands 11/2021 Candelaria B Portugal, Madeira - Call sign: CQMB Owner: Peter Döhle Schiffahrts K.G., Las Palmas (Gran Canaria) - Spain Manager: Boluda Lines S.A., Las Palmas (Gran Canaria) - Spain |
|
Latest data adjustment |
12 July 2023 |
