| Westerschelde 13 May 2020 |
 |
|
| Westerschelde 24/02/18 | |
|
Name |
MOL EMISSARY |
|
Type |
Cellular containership - Panamax |
|
IMO-number |
9407158 |
|
Call sign |
VRFX6 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
54.940 t |
|
DWT |
Summer: 67.170 t |
|
NT |
35.134 t |
|
Number of 20ft containers |
In hold: 2.203 On deck: 2.838 Total: 5.041 |
|
Container capacity 14t |
3.340 |
|
Reefer capacity |
600 |
|
Length |
294,13 m overall 283,79 m between perpendiculars |
|
Breadth |
32,68 m extreme 32,20 m moulded |
|
Draught |
Summer: 13,67 m |
|
Depth |
22,10 m |
|
Speed |
Service: 23,5 knots Max: 24,7 knots |
|
Built |
2009 |
|
Keel laid |
22/06/2009 |
|
Launch date |
11/09/2009 |
|
Date of completion |
20/11/2009 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. Ulsan South Korea |
|
Yard number |
1972 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8RTA96C - 2 stroke single acting 8 cylinder 960 x 2.500 mm combustion engine Mcr 45.760 kW / 62.215 hp at 102,0 rpm |
|
Propellers |
1x Fixed pitch mono-block propeller - aft at 102,0 rpm |
|
Boilers |
1x Auxiliary boiler, composite Mission OC Builder: Aalborg Industries AS |
|
Generators |
4x Hyundai/Himsen 7H25/33 - 4 stroke 7 cylinder 250 x 330 mm diesel engines each Mcr 2.100 kW connected with generators each 1.980 kW |
|
Emergency generator |
1x Cummins 6CTA-8.3-D(M) diesel generatorset |
|
Bow thruster |
1x Tunnel thruster 1.800 kW / 2.447 bhp, forward |
|
Tank capacities |
Ballast: 17.351,1 m³ |
|
Anchor equipment |
Length: 715,00 m Diameter: 90 mm |
|
Cargo gear |
Gearless |
|
Crew size |
21 |
|
Commercial manager |
MOL - Mitsui OSK Lines Ltd. 1-1, Toranomon 2-chome, Minato-ku Tokyo, 105-8688 Japan |
|
ISM Manager |
Seaspan Ship Management Ltd. Suite 2600, 200, Granville Street Vancouver BC V6C 1S4 Canada |
|
Registered owner |
Seaspan Corporation Unit 2, 16th Floor, W668 Building, 668, Cheung Sha Wan Road, Kowloon Hong Kong China |
|
Renamed |
04/2022 Seaspan Emissary Hong Kong, china - Call sign: VRFX6 Owner: Seaspan Corporation Manager: Seaspan Ship Management Ltd. |
|
Latest data adjustment |
25 March 2024 |
