Name |
MAERSK EINDHOVEN |
|
Previous names |
2010 - 2010 Aqua Rickmers |
|
Type |
Cellular containership - Dangerous goods |
|
IMO-number |
9456771 |
|
Call sign |
OXFG2 |
|
Flag |
Denmark |
|
Port of registry |
København |
|
Previous flags |
2010 - 2017 Marshall islands, Majuro - Call sign: V7UQ7 |
|
GT |
141.716 t |
|
DWT |
Summer: 142.105 t |
|
NT |
59.810 t |
|
Number of 20ft containers |
13.092 |
|
Container capacity 14t |
9.082 |
|
Reefer capacity |
800 |
|
Length |
366,46 m overall 352,83 m between perpendiculars |
|
Breadth |
48,20 m |
|
Draught |
Summer: 15,50 m |
|
Depth |
29,85 m moulded |
|
Speed |
Max: 24,7 knots |
|
Built |
2010 |
|
Keel laid |
29/03/2010 |
|
Launch date |
25/06/2010 |
|
Date of completion |
16/08/2010 |
|
Builder |
12/20017 - 11/2019 Hyundai Heavy Industries Co., Ltd. Ulsan South Korea |
|
Yard number |
2152 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom continuous from peak to peak bulkhead |
|
Watertight bulkheads |
12 |
|
Continuous decks |
2 |
|
Main engine |
1x Wärtsilä 12RT-Flex96C-B - 2 stroke 12 cylinder 960 x 2.500 mm combustion engine 68.640 kW at 102,0 rpm Build: 2010 Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Propellers |
1x Solid propeller (keyless) - aft at 102,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 8,83 bar Heating surface: 73,4 m² 1x Steam boiler, exhaust gas heated - 12,23 bar Heating surface: 484,0 m² Build: 2010 Manufacturer: KangRim Industries Co., Ltd. (3rd Factory) |
|
Electric installations |
1x Plant 6.600 V - 3.600 kVA 1x Plant 6.600 V - 3.600 kVA 1x Plant 6.600 V - 3.600 kVA 1x Plant 6.600 V - 3.600 kVA 1x Plant 6.600 V - 3.600 kVA 1x Plant 450 V - 370 kVA 2x Plants each 24 V - 7 Ah 1x Plant 24 V - 12 Ah 12x Plants each 24 V - 200 Ah 12x Plants each 24 V - 300 Ah |
|
Generators |
5x HimSen 6H32/40 diesel generatorsets each 3.600 kVA |
|
Emergency generator |
1x Diesel generatorset 370 kVA |
|
Batteries |
12x Batteries for UPS navigation each 300 Ah 12x Batteries for UPS radio each 200 Ah 1x Battery for automation 12 Ah 2x Batteries for start emergency engine each 7 Ah |
|
Compressed air receivers |
2x Receivers each 16.800 litres - 29,4 bar 1x Receiver 480 litres, 29,4 bar 1x Receiver 300 litres, 8,8 bar 1x Receiver 2.000 litres, 8,6 bar |
|
Bow thruster |
2x Transverse thruster each 1.800 kW, forward |
|
Anchor equipment |
3x Anchors weight each 24.500 kg Chain length: 770.00 m |
|
Crew size |
36 |
|
Operator |
Maersk A/S Esplanaden 50 1263 København Denmark |
|
Registered owner |
Ocean Fei Shipping Ltd. |
|
Latest data adjustment |
08 October 2020 |
