| Westerschelde 14 December 2011 |
 |
 |
|
| Westerschelde 14/12/11 | Westerschelde 14/12/11 |
|
Name |
OOCL FINLAND |
|
Previous names |
Anina |
|
Type |
Cellular containership |
|
IMO-number |
9354351 |
|
Call sign |
MMYD4 |
|
Flag |
United Kingdom |
|
Port of registry |
London |
|
GT |
11.622 t |
|
DWT |
13.740 t |
|
NT |
7.284 t |
|
Number of 20ft containers |
868 |
|
Container capacity 14t |
720 |
|
Reefer capacity |
234 |
|
Length |
149,14 m overall 139,79 m registered |
|
Breadth |
22,50 m registered |
|
Draught |
8,70 m |
|
Forecastle |
91,39 m |
|
Poop |
9,45 m |
|
Freeboard |
2.609 mm |
|
Depth |
11,30 m |
|
Speed |
Max.: 18,5 knots |
|
Built |
2006 Ship lengthened 2008-09 |
|
Keel laid |
30.11.2004 |
|
Launch date |
18.04.2006 |
|
Date of completion |
15.06.2006 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. |
|
Yard number |
1234 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
4 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 9M43C - 4 stroke 9 cylinder 430 x 610 mm diesel engine - 8.400 kW at 500 rpm Year of manufacture: 2006 Manufacturer: Caterpillar Motoren GmbH & Co. KG |
|
Propellers |
1x Controllable pitch propeller - aft 128 rpm |
|
Boilers |
1x Thermal oil heater, oil fired - 10,0 bar Heating surface: 51,7 m² 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 221,5 m² Year of manufacture: 2006 Manufacturer: PWT Prozess-Wärmeträgertechnik GmbH |
|
Electric installations |
1x Plant 400 V - 1.155 kVA 1x Plant 400 V - 1.390 kVA 1x Plant 400 V - 1.860 kVA 1x Plant 400 V - 400 kVA 1x Plant 24 V - 140 Ah 1x Plant 400 V - 192 Ah |
|
Shaft generator |
1x 1.488 kW / 1.860 kVA |
|
Generators |
1x Main diesel generatorset 1.112 kW / 1.390 kVA 1x Main diesel generatorset 924 kW / 1.155 kVA |
|
Emergency generator |
1x Diesel generatorset 400 kVA |
|
Compressed air receivers |
2x Receivers each 750 litres - 30,0 bar 1x Receiver 500 litres - 11,0 bar |
|
Thruster |
1x Transverse thruster 750 kW, forward 1x Transverse thruster 450 kW, aft |
|
Anchor equipment |
3x Anchors weight each 5.250 kg Chain length: 577,50 m |
|
Cargo gear |
None |
|
Crew size |
19 |
|
Manager |
Peter Döhle Schiffahrts-KG |
|
Operator |
OOCL - Orient Overseas Container Line |
|
Owner |
Anina Shipping Ltd. IOM |
|
Renamed |
2012 Gorky Park |
