Tapiola - IMO 7705934

Name

TAPIOLA

Previous name

1978-1989 Boogabilla

Type

Roll-On/Roll-Off Vehicles Carrier
PCTC - Pure Car and Truck Carrier

IMO-number

7705934

Call sign

9V6486

Flag

Republic of Singapore

Previous flags

1989 Sweden

2004 Norway

Port of registry

Singapore

GT

39.535 t

DWT

31.456 t

NT

13.678 t

Length

228,41 m overall
210,00 m between perpendiculars

Breadth

32,26 m overall

Draught

Summer: 10,82 m

Air draft

57,00 m

Freeboard

9.400 mm

Depth

20,20 m to upperdeck

Speed

20,5 knots

Built

1978

Rebuild: 2004 Converted by replacing container space on deck 4 and adding extra car decks by Chengxi Shipyard China

Launch date

10.03.1978

Date of completion

25.08.1978

Builder

Mitsubishi Heavy Industries Ltd
Nagasaki Shipyard & Engine Works
1-1 Akunoura-machi
Nagasaki City 850-8610
Japan

Yard number

1831

Hull type

Single hull

Main engine

1x Sulzer 9RND90M diesel engine output 20.000 kW at 118 rpm with remote control from bridge or control room

Propeller

1x Fixed 5 blades propeller with diameter 6.800 mm

Generators

4x Daihatsu main diesel generatorsets:

2x Daihatsu 6DS 32 with an output of 1.550 kW each

2x Daihatsu 8DS 32 with 2.000 kW each

Thruster

2x Mitsubishi-Kamewa thrusters are installed, one forward and one aft

Winches

Forward deck: machinery consists of 2x 20 t electric combined windlass/mooring winces and one 10 t electric mooring winch

Amidships: 2x 10 t electric mooring winches

Aft: 2x 10 t and 2 x 20 t electric mooring winches

Car capacity (RT43)

3.961 or 440 trucks
1 RT43 unit = 7,38975 m²

Stern ramp width

Width: 12,00 m

Capacity: 400 t

Number of decks

12 (of which 3 are hoistable)

Bunker capacity

3.475 t

Lifting equipment

1x Electro/hydraulic crane 6 STBD on deck - SWL 5,0 t

Manager

Wilhelmsen Ship Managment (India) Pvt Ltd.

Previous manager

1978-2004 Barber Ship Management AS
c/o Barber Vessel Accounting Empire Tower 47th Floor 182 Jalan Tun Razak
Strandveien 20
1324 Lysaker
Norway

Charter

Wallenuis Wilhelmsen

Operator

Wilh. Wilhelmsen Group

Owner

Mark I Shipping Pte. Ltd

Wilhelmsen Ships Service AS

1324 Lysaker
Norway
