Glovis Spirit - IMO 9674165

Westerschelde 30 March 2019

Name

GLOVIS SPIRIT

Korean mane

글로비스 스피릿

Type

Roll-On/Roll-Off vehicles carrier

PCC - Pure car Carrier

IMO-number

9674165

Call sign

D8GO

Flag

South Korea

Port of registry

Jeju

Previous flag

09/2013 - 11/2020 Marshall Island, Majuro - Call sign: V7CA8

GT

64.824

DWT

Summer: 20.002 t

NT

22.540

Length

199,97 m overall

Breadth

35,40 m

Draught

10,01 m

Reg. Dimensions L x B x D

194,32 x 35,40 x 20,52 m

Rule Dimensions L x B x D

188,80 x 35,40 x 14,48 m

Freeboard

3.220 mm

Depth

20,52 m registered

Speed

Service: 20,23 knots

Built

2013

Keel laid

15/04/2013

Launch date

13/07/2013

Date of completion

26/09/2013

Builder

Hyundai Samho Heavy Industries Co. Ltd.

Yeongam

South Korea

Yard number

S667

Hull material

Steel

Main engine

1x MAN-B&W 7S60ME-C8 - 2 stroke single acting 7 cylinder 600 x 2.400 mm combustion engine 13.070 kW / 17.770 bhp at 102,0 rpm

Built: 26/03/2013

Builder: Hyundai Heavy Ltd. Engine & Machinery Division, Ulsan - South Korea

Propellers

1x Fixed pitch propeller

Boilers

1x Auxiliary Boiler WTB - 8,8 kg/cm²

Heating surface: 30,2 m²

1x Economizer EGE - 12,7 kg/cm²

Heating surface: 483,0 m²

Built: 28/02/2013

Builder: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea

Generators

1x Main diesel generatorset 1.250 kVA - 450 Volt

2x Main diesel generatorsets each 1.875 kVA - 450 Volt

Number of cars

7.280

Number of ramp

2

Tank capacities

Fuel oil: 3.452,2 m³

Fresh water: 320,7 m³

Water ballast: 9.233,2 m³

Commerical manager

Hyundai Glovis Co Ltd.

83-21, Wangsimni-ro, Seongdong-gu

Seoul

South Korea

ISM manager

G-Marine Service Co Ltd.

331, Jungang-daero, Dong-gu

Busan, 48792

South Korea

Operator

Glovis - part of the Hyundai Kia Automotive Group

Registered owner

Hyundai Glovis Co Ltd.

83-21, Wangsimni-ro, Seongdong-gu

Seoul

South Korea

Latest data adjustment

28 April 2025
