Westerschelde 09 April 2020 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 24/06/14 | Westerschelde 24/06/14 | Westerschelde 24/06/14 | Westerschelde 18/11/15 | Westerschelde 19/03/19 | Westerschelde 28/04/16 | |||||
|
Name |
GRAND BENELUX |
|
Type |
Roll-On/Roll-Off car carrier - Vehicle carrier |
|
IMO-number |
9227900 |
|
Call sign |
IBTB |
|
Flag |
Italy |
|
Port of registry |
Palermo |
|
GT |
37.712 t |
|
DWT |
12.594 t |
|
NT |
13.441 t |
|
Number of 20ft containers |
880 |
|
Length |
176,50 m overall 165,00 m between perpendiculars |
|
Breadth |
31,32 m |
|
Draught |
8,77 m |
|
Lane metres |
3.100 |
|
Depth |
14,46 m |
|
Speed |
20,1 knots |
|
Built |
2001 |
|
Keel laid |
20/10/2000 |
|
Date of completion |
06/08/2001 |
|
Builder |
Uljanik Shipyard Pula Croatia |
|
Yard number |
437 |
|
Hull material |
Ordinary steel |
|
Hull type |
Single hull |
|
Main engine |
1x MAN-B&W/Uljanik Strojogradnja 7S50MC -C - 2 stroke 7 cylinder 500 x 2.000 mm combustion engine 11.060 kW / 15.037 hp at 127,0 rpm Builder: Uljanik Brodogradiliste d.d. - Croatia |
|
Propellers |
1x Controllable pitch propeller |
|
Generators |
3x Main diesel generatorsets each 920 kW |
|
Bow thrusters |
1x 1.000 kW, forward 1x 800 kW, aft |
|
Number of cars |
4.632 |
|
Number of ramps |
2 |
|
Ramp capacity |
150 t |
|
Passengers |
12 passengers (6 cabins) |
|
Commerical manager |
Grimaldi Group Spa Via Marchese Campodisola 13 80133 Naples NA Italy |
|
ISM manager |
Grimaldi Euromed Spa Via Marchese Campodisola 13 80133 Naples NA Italy |
|
Registered owner |
ACL Ship Owners 2005 AB Care of Grimaldi Group Via Marchese Campodisola 13 80133 Naples NA Italy |
|
Latest data adjustment |
30 May 2022 |
