Cymbeline - IMO 9007764

Name

CYMBELINE

Type

Roll-On/Roll-Off carrier

IMO-number

9007764

Call sign

9HA4432

Flag

Malta

Port of registry

Valletta

Previous flags

• 1992 Denmark

• 1993 Republic of Panama

• 2012 - 2017 Grand Duchy Of Luxembourg, Luxembourg City - Call sign: LXCZ

• 2017 - 2019 Malta, Valletta - Call sign: 9HA4432

• 10/2019 - 11/2019 St Vincent Grenadine

GT

11.866 t

DWT

7.000 t

NT

3.559 t

Number of 20 ft containers

514

Reefer capacity

44

Length

147,40 m overall

137,10 m between perpendiculars

Breadth

21,03 m extreme

Draught

Summer: 5,32 m

Lane metres

1.475 m

Keel to mast end

36,00 m

Freeboard

6.670 mm

Depth

12,50 m

Speed

Max: 17,0 knots

Servixe: 13,0 knots

Built

1992

Keel laid

11/10/1991

Launch

30/04/1992

Date of completion

29/07/1992

Builder

Dalian New Shipyard

No. 1 Yan Hai Street

116005 Dalian

Liaoning Province

China

Yard number

R-70/4

Hull material

Steel

Hull type

Double hull

Bulkheads

Transverse: 5

Longitudinal: 2

Continuous decks

2

Main engine

2x MaK 8M453C - 4 stroke 8 cylinder 320 x 420 mm combustion engines total 4.770 kW / 6.486 hp at 600 rpm

Propellers

2x Controllable pitch propeller

Shaft generators

2

Generator

2x Deutz BA16M816KR diesel generatorsets each 860 kW

Emergency

1x Deutz F5K413FL diesel generator 112 kW

Bow thruster

1x Deutz TBD294V12 diesel engine 400 kW

Number of ramps

2

Tank capacities

Ballast: 4.611 m³

Manager

EuroShip Services Limited

Long Reach House (1st Floor), London Road

Purfleet

Essex RM19 1PD

United Kingdom

Operator

Compagnie Luxembourgoise d'Affretements S.A.

Rue de Merl 55 - 57

L-2146 Luxembourg

Grand Duchy Of Luxembourg

Registered owner

CLDN RO-RO SA

C/O Euroship Services Ltd. Long Reach House London Road

RM19 1PD Purfleet

United Kingdom

Previous owners

• 1992 - 2004 Cobelfret S.A. - Grand Duchy of Luxembourg

• 2004 - 2004 Compagnie Luxembourgoise d'Affretements S.A., 2146 Luxembourg - Grand Duchy Of Luxembourg

• 2004 - 2004 Cobelfret S.A. - Grand Duchy of Luxembourg

• 2004 - 2009 Compagnie Luxembourgoise d'Affretements S.A. – 2146 Luxembourg - Grand Duchy of Luxembourg

• 2009 - 2011 Cobelfret S.A - Grand Duchy of Luxembourg

• 2011 - 2011 CLDN RO-RO SA, C/O Euroship Services Ltd. Long Reach House - United Kingdom

• 2011 - 2011 CLdN ro-ro SA and Cobelfret NV, L-2519 Luxembourg - G.D. Luxembourg

Renamed

11/2019 Dalka

Chili, Valparaiso - Call sign: CA7878

Owner: Navimag Carga SA, Las Condes, Chile

Manager: Navimag Ferries S.A., Puerto Montt - Chile

Latest data adjustment

04 March 2023
