Westerschelde 17 September 2016 |
 |
 |
|
| Westerschelde 14/02/20 | Westerschelde 14/02/20 | |
|
Name |
HÖEGH NEW YORK |
|
Previous names |
2005 build as: Hual Detroit 04/2005 - 09/2005 Höegh New York 09/2005 - 08/2010 Alliance New York 08/2010 - 05/2014 Prestige New York |
|
Type |
Roll-On/Roll-Off carrier - Vehicle carrier |
|
IMO-number |
9295830 |
|
Call sign |
LAUA7 |
|
Flag |
Norway |
|
Port of registry |
Oslo |
|
Previous flags |
USA - Call sign: KDUE |
|
GT |
57.280 t |
|
DWT |
21.099 t |
|
NT |
19.535 t |
|
Length |
199,90 m overall 190,00 m between perpendiculars |
|
Breadth |
32,29 m extreme |
|
Draught |
Summer: 10,02 m |
|
Depth |
32,59 m |
|
Speed |
Max: 20,5 knots |
|
Built |
2005 |
|
Keel laid |
22/11/2004 |
|
Launch date |
20/02/2005 |
|
Date of completion |
22/04/2005 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co., Ltd. Geoje South Korea |
|
Yard number |
4435 |
|
Hull material |
Steel |
|
Bulkheads |
Transverse: 2 |
|
Main engine |
1x MAN-B&W 7S60MC - 2 stroke 7 cylinder 600 x 2.292 mm combustion engine 12.138 kW / 16.503 hp at 105,0 rpm |
|
Propellers |
1x Fixed pitch mono-block propeller Builder: Mecklenburger Metallguss Waren GmbH |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated AV-7 1x Auxiliary boiler, oil/gas fired Mission OS Builder: Aalborg Industries A/S |
|
Generators |
3x MAN 7L28/32H main diesel generatorsets each 1.470 kW |
|
Emergency generator |
1x Cummins LTA-10D(M) diesel generatorset |
|
Bow thruster |
1x Nakashima TCT-260 - 1.800 kW, forward |
|
Number of decks |
12 |
|
Number of ramps |
2 1x Side port: 25,00 x 6,50 m - SWL 22,0 t 1x Aft 38,00 x 7,00 m - SWL 150,0 t |
|
Number of cars |
6.545 |
|
Tank capacities |
Ballast: 8.012,2 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 78 mm |
|
Commercial manager |
Höegh Autoliners Shipping AS Drammensveien 134 0277 Oslo Norway |
|
ISM manager |
Hoegh Technical Management Inc. Drammensveien 134 0277 Oslo Norway |
|
Registered owner |
Höegh Autoliners Shipping AS Drammensveien 134 0277 Oslo Norway |
|
Latest data adjustment |
08 April 2024 |
