| Westerschelde 15 September 2012 |
 |
 |
|
| Westerschelde 06/11/11 | Westerschelde 06/11/11 | |
|
Name |
ERAS |
|
Type |
Chemical / Oil products tanker |
|
IMO-number |
9400356 |
|
Call sign |
9HA2334 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
4.001 t |
|
DWT |
Summer: 5.717,10 t |
|
NT |
1.837 t |
|
Length |
105,50 m overall |
|
Breadth |
20,00 m |
|
Draught |
6,294 m |
|
Moulded L x B x D |
99,35 x 16,80 x 7,40 m |
|
Registered L x B x D |
99,35 x 16,80 x 7,40 m |
|
Freeboard |
Summer: 1.129 mm |
|
Depth |
7,40 m moulded |
|
Built |
2009 |
|
Keel laid |
05.06.2007 |
|
Date of completion |
09.06.2009 |
|
Builder |
Icdas Biga Factory |
|
Yard number |
NB11 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN - 4 stroke single acting 8 cylinder 270 x 380 mm diesel engine - 2.720 kW at 800 rpm Manufacturer: MAN Diesel A/S Frederikshavn |
|
Propeller |
1 |
|
Propeller Shaft |
1x Oil Lubrication shaft without monitoring device |
|
Boilers |
1x Auxiliary boiler - 1,20 Mpa / 12,0 bar Evaporation: 2.000 kW 1x Auxiliary boiler - 1,20 Mpa / 12,0 bar Evaporation: 1.500 kW Manufacturer: HTI |
|
Generators |
5x Diesel generatorsets 2.467 kVA |
|
Cargo Capacity |
6.580 m³ |
|
Tank capacities |
Fuel oil: 316 m³ Fresh water: 241 m³ Water ballast: 2.347 m³ |
|
Lifting equipment |
1x Crane - SWL 2,0 t 1x Crane - SWL 5,0 t |
|
Manager |
Mardeniz Shipping Managements Co., Inc. |
|
Operator |
Mardeniz Denizcilik Isletmeleri A.S. |
|
Owner |
Icdas Celik Enerji Tersane VE |
|
Registered owner |
(Bareboat Charterer)Seven Star Tankers Ltd. |
