| Westerschelde 17 September 2016 |
|
Name |
ELM K |
|
Type |
Geared general cargo ship |
|
IMO-number |
9614294 |
|
Call sign |
3EVH2 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GRT |
20.992 t |
|
DWT |
32.836 t |
|
NRT |
11.228 t |
|
Length |
181,16 m overall |
|
Breadth |
28,40 m moulded |
|
Draught |
Summer: 10,03 m |
|
Moulded L x B x D |
172,50 x 28,40 x 14,25 m |
|
Registered L x B x D |
173,45 x 28,40 x 14,25 m |
|
Freeboard |
Summer: 4.292 mm |
|
Depth |
14,25 m moulded |
|
Speed |
Max: 16,5 knots Service: 14,0 nots |
|
Built |
2012 |
|
Keel laid |
14/11/0201 |
|
Launch date |
05/07/2012 |
|
Date of completion |
30/10/2012 |
|
Builder |
Kanda Shipbuilding Kure Japan |
|
Yard number |
532 |
|
Hull material |
Steel |
|
Hull type |
Double hull construction applied to all cargo hold |
|
Main engine |
1x Mitsubishi 6UEC45LSE - 2 stroke single acting 6 cylinder 450 x 1.840 mm combustion engine 6.000 kW / 8.158 hp at 114,0 rpm Manufacturer: Kobe Diesel Co., Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 455 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 0,78 MPa Evaporation: 1,84 t/h Manufacturer: Osaka Boiler Mfg. Co., Ltd. |
|
Generators |
4x Generatorsets total 1.750 kVA |
|
Number of holds |
5 |
|
Cargo hold capacity |
Bale: 41.964 m³ Grain: 43.488 m³ |
|
Tank capacities |
Fuel oil: 1.671 m³ Fresh water: 269 m³ |
|
Cargo gear |
4x Deck cranes - SWL 30,0 t each |
|
Manager |
First Marine Service Co., Ltd. |
|
Registered owner |
Sealift Maritime SA Care of Misuga Kaiun Co Ltd. 1692-2, Nakanosho-cho, Shikokuchuo-shi, Ehime-ken, 799-0422 Japan |
|
Latest data adjustment |
06 April 2024 |
