Name |
HENRICUS J |
|
Previous names |
Industrial Dolphin BBC Tasmania |
|
Type |
General cargo vessel - Equipped for carriage of containers |
|
IMO-number |
9360192 |
|
Call sign |
V2CZ2 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John’s |
|
GRT |
7.223 t |
|
DWT |
7.996 t |
|
NRT |
2.918 t |
|
Number of 20ft containers |
In hold: 204 On deck: 302 Total: 506 |
|
Reefer capacity |
80 |
|
Length |
119,84 m overall |
|
Breadth |
20,00 m |
|
Draught |
Summer: 7,71 m |
|
Moulded L x B x D |
112,00 x 20,00 x 11,30 m |
|
Registered L x B x D |
114,19 x 20,00 x 11,30 m |
|
Freeboard |
3.615 mm |
|
Depth |
11,30 m |
|
Speed |
Max: 16,1 knots |
|
Built |
2007 |
|
Keel laid |
24/04/2007 |
|
Launch date |
04/08/2007 |
|
Delivery date |
12/10/2007 |
|
Builder |
ENVC - Estaleiros Navais De Viana Do Castelo, S.A. Avenida Praia do Norte |
|
Yard number |
228 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Single hull double bottom |
|
Watertight bulkheads |
7 |
|
Number of decks |
2 |
|
Main engine |
1x MaK 6M43 - 4 stroke single acting 6 cylinder 430 x 910 mm combustion engine 5.400 kW / 7.342 bhp at 800 rpm Manufacturer: Caterpillar Motoren Gmbh & Co. KG |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 690 mm |
|
Propellers |
1x Controllable pitch propeller - aft at 150 rpm |
|
Boilers |
1x Thermal oil heater, oil fired - 13,0 bar Heating surface: 20,0 m² 1 x Thermal oil heater, exhaust gas heated - 13,0 ba Heating surface: 93,0 m² |
|
Electric installations |
2x Plant 380/220 V each 437 kVA 1x Plant 380 V - 875 kVA 1x Plant 380 V - 437 kVA |
|
Shaft generator |
1x 875 kVA |
|
Generators |
2x Main diesel generatorsets each 437 kVA |
|
Emergency generator |
1x Diesel generatorset 437 kVA |
|
Compressed air receivers |
2x Receivers each 500 litres - 30,0 bar 1x Receiver 150 litres - 30,0 bar 1x Receiver 100 litres - 15,0 bar |
|
Bow thruster |
1x Transverse thruster 450 kW, forward |
|
Number of holds |
3 |
|
Cargo hold capacity |
Bale & grain: 11.820 m³ / 395.000 ft³ |
|
Number of hatches |
3 Hatch 1: 16,85 x 10,60 m / 15,80 m - 2 panels Hatch 2: 42,42 x 15,80 m - 4 panels Hatch 3: 12,47 x 15,80 m - 1 panel |
|
Tank capacities |
Fuel oil: 885,56 m³ Fresh water: 154,74 m³ Ballast water: 4.190 m³ |
|
Anchor equipment |
3x Anchors weight each 4.320 kg Chain length: 550,00 m |
|
Cargo gear |
2x Electro-hydraulic cranes - SWL 200 t each Cranes Combination: SWL 400 t |
|
Crew size |
16 |
|
Manager |
Jungerhans Maritime Services GmbH & Co., KG Germany |
|
Owner |
Henricus J Shipping GmbH & Co., KG Haren /Em Germany |
|
Renamed |
2017 - 2019 Industrial Dolphin Antigua& Barbuda, St. John’s - Call sign: V2CZ2 2019 BBC Dolphin Antigua& Barbuda, St. John’s - Call sign: V2CZ2 Reg. Owner: MS "HENRICUS J" Schiffahrtsgesellschaft UG (haftungsbeschraenkt) & Co. KG Manager: Juengerhans Heavy-Lift-Fleet Services GmbH & Co. KG |
|
Latest data adjustment |
19 July 2023 |
