Antwerpen 28 August 2018 |
 |
 |
 |
||
| Antwerpen 06/04/18 | Antwerpen 06/04/18 | Antwerpen 28/09/19 |
|
Name |
HENRIK S |
|
Previous names |
Built as: 2007 Narjan 2007 - 05/2009 Sloman Sprinter 05/2009 - 11/2017 Norjan |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
9347633 |
|
Call sign |
3FMX6 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
Previous flags |
2007 - 2009 G.D. Luxembourg, Luxembourg City - Call Sing: LXNJ 2009 - 2017 Antigua & Barbuda, St. John’s - Call sign: V2GP4 |
|
GT |
8.407 t |
|
DWT |
Summer: 11.169 t |
|
NT |
4.215 t |
|
Number of 20ft containers |
In hold: 272 On deck: 404 Total: 676 |
|
Container capacity 14t |
367 |
|
Reefer capacity |
60 |
|
Length |
129,49 m overall 121,32 m between perpendiculars |
|
Breadth |
19,00 m moulded |
|
Draught |
8,70 m |
|
Forecastle |
28,31 m |
|
Poop |
19,68 m |
|
Depth |
11,65 m |
|
Speed |
Service: 12,0 knots Max: 16,5 knots |
|
Built |
2007 |
|
Keel laid |
22/12/2006 |
|
Launch date |
29/04/2007 |
|
Date of completion |
20/07/2007 |
|
Builder |
Daehan Shipbuilding Co., Ltd. 748, Woodoo-ri, Dolsan-up Yeosu, Cheollanam-do 550-831 Republic of Korea |
|
Yard number |
H503 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
11 |
|
Number of decks |
1 |
|
Main engine |
1x MaK 6M43C - 4 stroke single acting 6 cylinder 430 x 610 mm combustion engine 6.000 kW / 8.158 bhp at 500 rpm Year of manufacture: 2006 Manufacturer: Caterpillar Motoren GmbH & Co. KG Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 124,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 8,83 bar Heating surface: 15,0 m² 1x Steam boiler, exhaust gas heated - 8,83 bar Heating surface: 72,0 m² Year of manufacture: 2006 Manufacturer: KangRim Industries Co., Ltd. (3rd Factory) 40, Wongnam-dong Changwon Republic of Korea |
|
Electric installations |
3x Plants each 450/220 V - 450 kVA 1x Plant 450 V - 875 kVA 1x Plant 450 V - 125 kVA |
|
Shaft generator |
1x 875 kVA / 700 kW |
|
Generators |
3x Yanmar 6NY16L-SN - 4 stroke 6 cylinder 160 x 200 mm diesle engine each 450 kW / 543 hp coupled with generators each 563 kVA |
|
Emergency generator |
1x Cummins 6BT5.9-D(M) diesel generatorset 156 kVA - 125 kW - 152 hp |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 30,0 bar 1x Receiver 100 litres - 30,0 bar 1x Receiver 150 litres - 7,6 bar |
|
Bow thruster |
1x Transverse thruster 500 kW / 680 bhp, forward |
|
Number of holds |
2 Hold No.1: 18,90 x 15,60 x 11,00 m Lower hold no.1: width at 15,60 m - length 7,00 m / width at 10,00 m length Hold No.2: 58,20 x 15,60 x 11,0 m (3 compartments in hold 2) |
|
Cargo hold capacity |
Bale: 13.565 m³ Grain: 14.237 m³ |
|
Number of hatches |
2 Hatch 1: 18,90 x 15,60 m Hatch 2: 58,20 x 15,60 m |
|
Type of hatch covers |
Pontoon type - 13 pieces |
|
Tank capacities |
Fuel oil: 1.021,55 m³ |
|
Anchor equipment |
3x Anchors weight each 4.590 kg Chain length: 550,00 m Diameter: 60 mm |
|
Cargo gear |
2x Liebherr cranes - SWL 60,0 t each Combinable at 120 t |
|
Crew size |
17 |
|
Manager |
Allegro Shipping & Trading Ltd. Kat 1, 3/1 Sokak 2, Sumer Mah, Zeytinburnu 34025 Istanbul Turkey |
|
Owner |
Allegro Shipping & Trading Ltd. |
|
Latest data adjustment |
14 March 2020 |
