Warmia - IMO 9285146

Name

WARMIA

Type

Bulk carrier

IMO-number

9285146

Call sign

C6TY2

Flag

Bahamas

Port of registry

Nassau

GRT

24.109 t

DWT

Summer: 38.981 t

Winter: 37.875 t

NRT

13.253 t

Displacement

8.860 t

Length

189,99 m overall

183,70 m between perpendiculars

Breadth

29,56 m extreme

Draught

Summer: 10,58 m

Winter: 10,36 m

Depth

15,10 m

Speed

11,0 knots laden

11,5 knots ballast

Max: 14,2 knots

Built

2005

Keel laid

30/10/2003

Launch date

22/07/2005

Date of completion

14/10/2005

Builder

Tianjin Xingang Shipbuilding Heavy Industry Co., Ltd.

China

Yard number

345-4

Hull material

Steel

Hull type

Double skinned

Continuous decks

1

Main engine

1x Wärtsilä NSD (Sulzer) 6RTA48T-B - 6 cylinder combustion engine 7.368 kW / 10.018 hp at 118,0 rpm

Propellers

1x Fixed pitch mono-block propeller

Boilers

1x Auxiliary boiler, composite Mission OC

Builder: Alfa Laval Aalborg A/S

Generators

3x Wärtsilä 4L20 main diesel generatorsets each 635 kW

Number of holds

5

Hold 1: 24,80 x 26,30 x 14,21 m

Hold 2: 31,20 x 26,30 x 13,82 m

Hold 3: 31,20 x 26,30 x 13,82 m

Hold 4: 31,20 x 26,30 x 13,82 m

Hold 5: 28,80 x 25,00 x 13,82 m

Cargo hold capacity

Grain:

Hold 1: 7.588 m³ / 267.960 ft³

Hold 2: 10.761 m³ / 380.008 ft³

Hold 3: 10.761 m³ / 380.008 ft³

Hold 4: 10.761 m³ / 380.008 ft³

Hold 5: 9.064 m³ / 320.087 ft³

Total: 48.935 m³ / 1.728.072 ft³

Number of hatches

5

Hatch 1: 16,00 x 16,00 x 0,82 m

Hatch 2: 22,40 x 18,00 x 0,82 m

Hatch 3: 22,40 x 18,00 x 0,82 m

Hatch 4: 22,40 x 18,00 x 0,82 m

Hatch 5: 21,60 x 18,00 x 0,82 m

Tank capacities

Ballast: 22.667,7 m³

Fuel: 1.7771,2 m³

Fresh water: 368,2 m³

Cargo gear

4x Deck cranes - SWL 30,0 t each

Crew size

29

ISM & commercial manager

Polsteam Polska Żegluga Morska P.P. (Polish Steamship Company)

Szczecin

Poland

Registered owner

Nero Four Shipping Ltd.

Nassau

Bahamas

Latest data adjustment

01 June 2023
