Westerschelde 30 July 2018 |
 |
 |
 |
||
| Westerschelde 30/07/18 | Westerschelde 03/06/19 | Vlissingen 30/01/20 | ||
|
Name |
NOORDHOEK PATHFINDER |
|
Type |
ROV - Offshore support survey vessel Diving support vessel |
|
IMO-number |
9545663 |
|
Call sign |
PBYN |
|
Flag |
The Netherlands |
|
Port of registry |
Zierikzee |
|
GT |
1.659 t |
|
DWT |
Summer: 1.810 t |
|
NT |
497 t |
|
Length |
61,87 m overall 57,27 m between perpendiculars |
|
Breadth |
12,80 m moulded |
|
Draught |
Summer: 4,65 m |
|
Depth |
5,50 m moulded |
|
Speed |
12,0 knots |
|
Built |
2010 |
|
Keel laid |
18/12/2008 |
|
Date of completion |
25/03/2010 |
|
Builder |
Scheepswerf De Hoop Lobith Tolkamer The Netherlands |
|
Yard number |
438 |
|
Hull material |
Steel |
|
Number of decks |
1 |
|
Engines |
Diesel-electric 2x Caterpillar C32 - 4 stroke 145 x 162 mm combustion engines total 3.190 kW / 4.236 hp at 1.800 rpm |
|
Propulsion |
1x Veth thruster 900 kW 2x Azimuth fixed pitch propeller each 900 KW 2x Forward controllable thrusters each 350 kW |
|
Emergency generator |
1x Diesel generatorset 105 kW |
|
Bow thrusters |
2x 350 kW each |
|
Deck layout |
360 m² |
|
Max permitted loads |
5,0 t/m² |
|
Moon pool |
3x 25,00 m |
|
Tank capacities |
Fuel oil: 600 m³ Fresh water: 150 m³ Ballast water: 400 m³ Lubricant oil: 8 m³ |
|
Lifting equipment |
1x Crane - SWL 25,0 t |
|
Accommodation |
Complement: 40 passengers, 4 offices, recreation and mess room |
|
ISM & commercial manager |
Noordhoek Shipping 3 BV 4th Floor, Wilgenbos 2 3311 JX Dordrecht The Netherlands |
|
Operator |
N-Sea Wilgenbos 2 (4th Floor) 3311 JX, Dordrecht The Netherlands |
|
Registered owner |
Hanzevast Shipping 5 BV Care of Noordhoek Shipping 3 BV 4th Floor, Wilgenbos 2 3311 JX Dordrecht The Netherlands |
|
Latest data adjustment |
23 July 2022 |
