Evergem - IMO 9035008

Name

EVERGEM

Previous names

1993 - 2000 Thomas Letzer
2000 Evergem

Type

Harbour tug

IMO-number

9035008

Call sign

ORLH

Flag

Belgium

Port of registry

Antwerpen

GT

249 t

NT

74 t

Length

31,99 m overall
27,28 m between perpendiculars

Breadth

8,70 m overall

Draught

Max.: 4,65 m

Speed

Max.: 13,0 knots
Economic: 9,0 knots

Bollard pull

39

Built

1993

Launch data

06.05.1993

Delivered

30.06.1993

Builder

NV Scheepswerf van Rupelmonde
Rupelmonde
Belgium

Yard number

472

Main engine

1x ABC type MDZC-800-173 K - 4 stroke 8 cylinder diesel engine - output 2.719 bhp / 2.000 kW at 800 rpm
Built: 1990
Builder: Anglo Belgian Corporation N.V.
Wiedauwkaai 43
9000 Gent
Belgium

Propeller

1x Fixed pitch Combi
Diameter: 2.700 mm 4-blade propeller in a Kort nozzle rudder

Gearbox

Reintjes ZWA V 2650 reduction

Generators

2x Scania DS11-60M diesel engines (200 kW continuous rating) each driving a ’Van Kaick’ alternator resulting in a total power output of 300 kVA - 3 x 380 V - 50 Hz

Bow thruster

7 t

Deck equipment

Remote controlled hydraulic driven towing/bridle winch Brusselle type HSL 70/2-2/1 with double drum on aft deck.
Towing winches: Brake holding: 80 t - dynamic: 18 t at 13,4 m/min, slack rope speed: 50 m/min. Anchor winch: 2x 4,6 t at 18,0 m/min, two speck-type anchors, 420 kg each with 275 m U2 chain diameter 19,0 mm
Bridle winch: static pull 40 t, dynamic: 20 t at 12,0 m/min.
Towing hook with pneumatic release device - SWL 30 t

Bollard pull

Ahead 39 t
With main engine and azimuth bow thruster 39 t
With azimuth bow thruster only 7 t

Tank capacities

Potable water: 19,0 m³
Fuel oil: 79,0 m³

Navigation equipment

Radar: Furuno FR-2115
Echo-sounder: Furuno FCV-585
GPS: Raytheon NAV-398
Magnetic compass: Cassens & Plath Type 11
VHF: Sailor RT-2048/RT-2047
Electronic charting system

Accommodation

Air-conditioned accommodation for 8 persons

Operator

SMIT Harbour Towage Division B.V.
3350 AA Papendrecht
The Netherlands

Owner

URS België N.V
Italiëlei 3 bus 2
2000 Antwerpen
Belgium

Group

Royal Boskalis Westminster N.V.
N.V. Boskalis Offshore transport Services
Rosmolenweg 20
3350 AA Papendrecht
The Netherlands

Note

COMBI - Fitted with retractable azimuth bow thruster

Renamed

2015 Multratug 1

Latest data adjustment

12 April 2015
