| Westerschelde 17 February 2016 |
|
Name |
HARMONIE |
|
Previous names |
1919 - 1928 Emanuel 1922 - 1928 Harmonie III 1928 - 1956 Friso 1956 - 1961 Susanna 1961 - 1994 Maaskade 1994 - 2001 Louise 2001 - 2007 Maaskade |
|
Type |
Tug - Pusher |
|
ENI-number |
02328748 |
|
Flag |
The Netherlands |
|
Tonnage |
8,0 t |
|
Length |
22,05 m |
|
Breadth |
5,20 m |
|
Draught |
Max: 2,20 m |
|
Air draft |
5,10 m |
|
Built |
1919 1955 converted to motor tugboat Refit: 2016 |
|
Builder |
Marckmann & Faassen Capelle a/d IJssel The Netherlands |
|
Hull material |
Steel |
|
Main engine |
1x Mitsubishi S6R MPTAW combustion engine 811 hp Build: 2016 |
|
Gearbox |
Masson W3450 Build: 2016 |
|
Previous engines |
160 hp Steam 500 hp Stork Werkspoor |
|
Propellers |
1 |
|
Generators |
1x Generator Lister - 22 kVA, 220V/380V 1x Generator hydraulic - 22 kVA 1x Generator Mitsubishi - 14 kVA |
|
Compressed air receivers |
1x Compressor 20,0 m³/h |
|
Bow thruster |
1x 60 kW |
|
Bollard pull |
8,0 t |
|
Deck equipment |
Manual tow hook 2x Winches Rubber push bow Anchor winch with 1 bow anchor and 50,00 m cable Aft anchor with 70,00 m cable |
|
Tank capacities |
Gas oil: 20,0 m³ Lub oil: 0,75 m³ Fresh water: 4,50 m³ |
|
Operator |
Rderij Driemast B.V. Handelskade 4 3434 BA Nieuwegein The Netherlands |
|
Owner |
Fam. Mastenbroek Nieuwegein The Netherlands |
|
Registered names & owner |
1919 - 1928 Emanuel - J. Overink, Hasselt - The Netherlands 1922 - 1928 Harmonie III - Harmonie III Sleepboot NV, Vreeswijk - The Netherlands 1928 - 1956 Friso - Gebrs. Roelofs NV, Rotterdam - The Netherlands 1956 - 1961 Susanna - R.L. Giessen, Rotterdam - The Netherlands 1961 - 1981 Maaskade - R.L. Giessen Scheepvaartbedrijf NV, Rotterdam - The Netherlands 1981 - 1986 Maaskade - W.C.H. Stelt, Maasbracht - The Netherlands 1986 - 1994 Maaskade - Limma Schiffahrt AG, Basel - Switzerland 1994 - 2001 Louise - A. Buitink, Spijkenisse - The Netherlands 2001 - 2007 Maaskade- B.P. Bulthuis, Rossum - The Netherlands |
|
Latest data adjustment |
12 May 2023 |
