| Vlissingen 04 January 2020 |
|
Name |
LEV TORNADO |
|
Previous names |
1979 - 2007 Tornado 2007 - 2012 SD Tornado |
|
Type |
Offshore support vessel Inspection ship - Salvage ship - Rescue vessel |
|
IMO-number |
7725453 |
|
Call sign |
DHVE2 |
|
Flag |
Germany |
|
Port of registry |
Bremen |
|
Previous flags |
United Kingdom - Call sign: GXUG |
|
GT |
550 t |
|
DWT |
174 t |
|
NT |
163 t |
|
Displacement |
698 t |
|
Length |
47,50 m overall 40,01 m between perpendiculars |
|
Breadth |
9,15 m moulded 5,58 m extreme |
|
Draught |
Summer: 3,50 m |
|
Depth |
5.01 m moulded |
|
Speed |
Max: 15,0 knots |
|
Built |
1979 Refit: 14/2013 |
|
Keel laid |
05/10/1978 |
|
Date of completion |
30/11/1979 |
|
Builder |
Hall Russell & Co., Ltd. Aberdeen - Scotland United Kingdom |
|
Yard number |
979 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
2x Mirrless Blackstone ESL 8MGR - combustion engine each 860 kW |
|
Propellers |
2 |
|
Generators |
3x Dorman Diesel 8JY VEE8 main diesel generatorsets each 117 kW / 440 Volt - 3 PH 60 Hz |
|
Clear deck space |
Approx. 200 m² |
|
Winch |
Towing decks winch with 200 m wire: 5,0 t |
|
Tank capacities |
MGO: 98,0 t Fresh water: 27,0 t |
|
Lifting equipment |
1x ATLAS Hydraulic AK6000V crane: SWL 5,0 t at a min of 1,00 m beyond starboard side SWL 2,0 t at a min of 4,00 m beyond starboard side |
|
Accommodation |
7 Crew + 10 passengers |
|
Navigation & communication equipment |
1x Echosounder: FURUNO FE-700 1x Gyro Compass: Sperry NAVIGAT X MK2 2x UKW/DSC: FURUNO FM-8900S 1x S-Band Radar: FURUNO FAR-2137S 1x X-Band Radar: JRC JMA 5300 MK2 1x MF/HF System: FURUNO FS-1575 GW/KW-DSC 1x AIS: FURUNO FA-150 1x GPS: FURUNO GPS Navigator GP-150 1x EPIRB: SAILOR SGE 406-II 1x ECDIS: TRANSAS NAVI-Sailor 4000 Premium 3x GMDSS: SAILOR SP 3520 1x SSAS: FURUNO FELCOM 19 SSAS 1x BNWAS: FURUNO BR-500 1x Autopilot: ROBERTSON AP9 with trackpilot |
|
Manager |
Innoven Marine Service GmbH & Co., KG Westkai 27572 Bremerhaven Germany |
|
Registered owner |
Lev Tornado GmbH & Co., KG Westkai 34 27572 Bremerhaven Germany |
|
Latest data adjustment |
05 May 2023 |
