Westerschelde 27 May 2017 |
 |
|
| Westerschelde 20/12/19 | |
|
Name |
TORM HORIZON |
|
Previous names |
2004 launch as: Athenian Horizon 07/2004 - 06/2008 Horizon |
|
Type |
Chemical & oil product tanker |
|
IMO-number |
9283710 |
|
Call sign |
OYNM2 |
|
Flag |
København |
|
Port of registry |
Denmark |
|
GT |
29.268 t |
|
DWT |
Summer: 46.955 t |
|
NT |
11.926 t |
|
Displacement |
56.245 t |
|
Light weight |
9.290 t |
|
Length |
183,20 m overall 174,00 m between perpendiculars |
|
Breadth |
32,20 m moulded 32,33 m extreme |
|
Draught |
Max: 12,22 m |
|
Keel to mast end |
50,64 m |
|
Freeboard |
8.945 mm |
|
Depth |
18,80 m moulded |
|
Speed |
Service: 13,5 knots Max: 16,4 knots |
|
Built |
2004 |
|
Keel laid |
13/02/2004 |
|
Date of completion |
28/06/2004 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. Ulsan South Korea |
|
Yard number |
0234 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Main engine |
1x HHI/MAN-B&W 6S50MC - 2 stroke 6 cylinder 500 x 1.910 mm combustion engine 8.561 kW / 11.669 bhp at 127,0 rpm Build: 17/02/2004 Builder: Hyndai Heavy Industries Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller |
|
Generators |
3x Main diesel generatorsets each 800 kW / 220 Volt 620 Hz |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Cargo tank capacity 100% |
53.808,8 m³ |
|
Number of pumps |
12x Cargo pumps each 600 m³/h |
|
Tank capacities |
Water ballast: 24.348,4 m³ |
|
Commercial manager |
Torm Shipping India Pvt Ltd. 2nd Floor, Leela Business Park, 55, Andheri-Kurla Road, Andheri (E) Mumbai, 400059 India |
|
ISM manager |
Torm A/S Tuborg Havnevej 18 2900 Hellerup Denmark |
|
Registered owner |
Torm A/S Tuborg Havnevej 18 2900 Hellerup Denmark |
|
Renamed |
2022 Hari Prakash India, Mumbai - Call sign: VTOE Owner: Castle Ships Pvt Ltd., Mumbai - India Manager: Castle Ships Pvt Ltd. |
|
Latest data adjustment |
22 October 2022 |
