Antwerpen 09 July 2019 |
|
Name |
TRAFUCO 9 |
|
Type |
Inland tanker |
|
ENI-number |
06105584 |
|
Call sign |
OT5392 |
|
Flag |
Belgium |
|
Port of registry |
Antwerpen |
|
GT |
983 t |
|
Tonnage |
1.500 t |
|
Length |
73,00 m overall |
|
Breadth |
9,60 m |
|
Draught |
3,40 m |
|
Depth |
4,68 m |
|
Built |
2017 |
|
Date of completion |
23/10/2017 |
|
Builder casco |
Kladovo Shipyard Kladovo Serbia |
|
Builder completion |
De Groot Scheepstechniek BV Dordrecht The Netherlands |
|
Yard number |
114 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
16 |
|
Continuous decks |
1 |
|
Main engine |
1x Mitsubishi S12A2-Z3MPTAW-3 - 4 stroke 12 cylinder 150 x 160 mm combustion engine 701 kW / 953 hp at 1.940 rpm Build: 01/12/2016 Builder: Mitsubishi Heavy Industries Engine & Turbocharger, Sagmihara - Japan |
|
Gearbox |
1x Masson Marine W3450 - reduction 5,476:1 |
|
Propellers |
1x Screw propeller solid - aft at 354 rpm |
|
Boilers |
1x CHO Heatmaster 23,50 m² - 10,0 bar |
|
Generators |
1x Diesel generatorset 93 kVA - 74 kW - 129 hp 1x Diesel generatorset 470 kVA - 376 kW - 476 hp |
|
Pumps |
2x Kampers type 2C126 cargo pumps each 80 m³/h |
|
Tank capacities |
Fuel: 28 m³ |
|
Operator |
Trafuco NV Molenberglei 6 2627 Schelle Belgium |
|
Registered owner |
Beltra-B N.V. Molenberglei 6 2627 Schelle Belgium |
|
Latest data adjustment |
26 March 2020 |
