Westerschelde 23 February 2019 |
 |
 |
 |
||
| Westerschelde 13/08/18 | Westerschelde 13/08/18 | Westerschelde 24/07/19 | ||
|
Name |
HABIP BAYRAK |
|
Type |
Tanker for oil and chemical |
|
IMO-number |
9458183 |
|
Call sign |
9HA5554 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
2010 - 2011 Turkey - Call sign: TCXC7 2011 - 2021 Marshall Islands, Monrovia - Call sign: V7WD7 |
|
GT |
5.672 t |
|
DWT |
Summer: 8.404,63 t Winter: 8.131 t |
|
NT |
2.604 t |
|
Length |
123,25 m overall 116,07 m between perpendiculars |
|
Breadth |
17,20 m moulded |
|
Draught |
Summer: 7,20 m Winter: 7,05 m |
|
Keel to mast end |
30,24 m |
|
Air draft |
32,70 m in ballast 30,23 m loaded condition |
|
Freeboard |
2.014 mm |
|
Depth |
9,20 m moulded |
|
Speed |
Max: 14,0 knots |
|
Built |
2010 |
|
Date of completion |
22/02/2010 |
|
Builder |
Ceksan Gemi Insa Celik Konstruksiyon Sanayi ve Ticaret A.S. Istanbul Turkey |
|
Yard number |
37 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Wärtsilä 8L32 - 4 stroke 8 cylinder 320 x 400 mm combustion engine 4.000 kW / 5.435 hp at 750 rpm Builder: Wärtsilä Finland Oy, Turku - Finland |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
1x CHR 44,00 m² - 10,0 bar 2x CHO 54,00 m² - 10,0 bar |
|
Shaft generator |
1x 1.375 kVA - 1.100 kW |
|
Generators |
3x Main diesel generatorsets each 725 kVA - 580 kW - 788 hp |
|
Emergency generator |
1x Diesel generatorset 163 kVA - 130 kW - 204 hp |
|
Bow thruster |
1x 440 kW |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Capacity of tanks 98% |
8.940,46 m³ excluding slop tanks |
|
Total cap. of tanks 98% |
9.136 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
169,61 m³ |
|
Pumps |
12x Cargo pumps each 250 m³/h 1x Cargo pump 50 m³/h 2x Ballast pumps each 300 m³/h |
|
Manifolds |
Distance from bow to centre manifold: 66,07 m Distance from stern to centre manifold: 57,18 m Distance between manifolds: 750 mm |
|
Tank capacities |
Fuel: 435,4 m³ Ballast: 3.841,9 m³ |
|
ISM & commercial manager |
Acechem Tanker Denizcilik Guzin Sokak 9/1, Aydintepe Mah Tuzla, 34947 Istanbul Turkey |
|
Registered owner |
MBI Shipping Trading Care of Acechem Tanker Denizcilik Turizm Sanayi ve Ticaret Ltd Sti. Guzin Sokak 9/1, Aydintepe Mah Tuzla, 34947 Istanbul Turkey |
|
Latest data adjustment |
19 January 2023 |
