Westerschelde 30 March 2018 |
|
Name |
TORM THAMES |
|
Previous names |
07/2005 - 05/2008 Thames |
|
Type |
Chemical tanker |
|
IMO-number |
9318333 |
|
Call sign |
OYNK2 |
|
Flag |
Denmark |
|
Port of registry |
København |
|
Previous flags |
07/2005 - 05/2008 Republic of the Marshall Islands |
|
GT |
29.214 t registered Suez: 30.615 t |
|
DWT |
Summer: 47.036 t |
|
NT |
12.307 t registered Suez: 26.062 t |
|
Length |
183,80 m overall 174,00 m between perpendiculars |
|
Breadth |
32,00 m moulded |
|
Draught |
10,90 m |
|
Freeboard |
6.412 mm |
|
Depth |
18,80 m moulded |
|
Speed |
15,7 knots |
|
Built |
2005 |
|
Keel laid |
04/04/2005 |
|
Launch date |
11/06/2005 |
|
Delivery date |
28/07/2005 |
|
Builder |
Hyundai Mipo Dockyard Co. Ltd. |
|
Yard number |
0430 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Bulkheads |
Water tight: 6 Oil tight: 7 |
|
Continuous decks |
1 |
|
Main engine |
1x HHI-EMD 7S50MC-C - 2 stroke 7 cylinder 500 x 2.000 mm combustion engine 11.635 kW at 127,0 rpm Manufacturer: Hyundai Heavy Industries Co.,Ltd. |
|
Propellers |
1x Wärtsilä controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler - 7,0 bar 1x Exhaust Gas Boiler - 7,0 bar Manufacturer: Kang Rim Ind.,Co., Ltd. |
|
Generators |
3x HHI-EES HFC6 508-14K main diesel generatorset each 840 kW |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity 100% |
53.689,6 m³ |
|
Number of slop tanks |
2 |
|
Pumps |
12x Cargo pumps each 600 m³/h 2x Cargo pumps each 300 m³/h |
|
Number of tanks |
Ballast: 14 Lubricating oil: 7 Fresh water: 6 Fuel oil: 5 Diesel oil: 3 Hydraulic oil: 2 Waste water: 2 Chain: 2 Slop: 2 Sludge: 1 |
|
Tank capacities 100% |
Diesel oil: 226 m³ / 192 t Freshwater: 695,8 m³ Fuel oil: 1.348,2 m³ / 1.334,71 t Hydraulic oil: 35.7 m³ Lube oil: 112,5 m³ / 101,25 t Tank ballast: 23.952,2 m³ / 24.551,0 t |
|
Lifting equipment |
1x Engine room overhead crane - SWL 2,0 t 1x Hose handling crane - SWL 10,0 t 1x Portside provision crane - 2,0 t 1x Starboard provision crane - 2,0 t |
|
Manager |
Torm A/S |
|
Operator |
Torm A/S |
|
Registered owner |
Vesselco 1 K/S |
|
Latest data adjustment |
25 July 2018 |
