Westerschelde 30 July 2016 |
 |
 |
 |
 |
|||
| Westerschelde 28/12/19 | Westerschelde 28/12/19 | Antwerpen 05/07/13 | Westerschelde 03/05/19 | |||
|
Name |
STEN FRIGG |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9407976 |
|
Call sign |
LAOJ8 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
Previous flags |
2009 - 2021 Gibraltar - Call sign: ZDIY4 |
|
GT |
11.935 t |
|
DWT |
Summer: 16.587 t |
|
NT |
5.133 t |
|
Length |
144,13 m overall 133,75 m between perpendiculars |
|
Breadth |
23,18 m extreme |
|
Draught |
8,91 m |
|
Depth |
12,41 m |
|
Speed |
13,5 knots |
|
Built |
2009 |
|
Keel laid |
31/07/2007 |
|
Launch date |
25/12/2007 |
|
Date of completion |
21/01/2009 |
|
Builder |
Jiangnan Shipyard (Group) Co., Ltd. Shanghai China |
|
Yard number |
H2400 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Wärtsilä 6L46 - 6 cylinder combustion engine 6.382 kW at 500 rpm Builder: Wärtsilä Finland Oy, Vaasa - Finland |
|
Propellers |
1x Control pitch propeller |
|
Boilers |
1x Auxiliary boiler, composite AQ-16 1x Auxiliary boiler, oil/gas fired AQ-9 Builder: Aalborg Industries A/S |
|
Shaft generator |
1x AVK SDCT65 generator 1.500 kW |
|
Generators |
2x Wärtsilä W4L20C main diesel generatorsets each 645 kW 1x Wärtsilä W6L20C main diesel generatorsets 970 kW |
|
Emergency generator |
1x Sisu 634DSBG diesel generatorset |
|
Bow thruster |
1x Brunvoll 750 kW |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity |
19.172 m³ |
|
Pumps |
12x Cargo pumps each 300 m³/h |
|
Tank capacities |
Ballast: 8.179,4 m³ HFO: 580 m³ Diesel oil: 74,8 m³ Fresh water: 502 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 58 mm |
|
Manager |
Rederiet Stenersen AS Edvard Griegs Vei 1 5059 Bergen Norway |
|
Registered owner |
Stentank AS Edvard Griegs Vei 1 5059 Bergen Norway |
|
Latest data adjustment |
23 May 2023 |
