Unique Explorer 01

Westerschelde 17 June 2014



Name

UNIQUE EXPLORER

Type

Oil carrier

IMO-number

9425526

Call sign

VRGT8

Flag

Hong Kong - China

Port of registry

Hong Kong

GT

28.465 t

DWT

Summer: 50.000 t

NT

14.372 t

Length

182,50 m overall

Breadth

32,20 m

Draught

Summer: 12,92 m

Moulded L x B x D

175,00 x 32,20 x 18,40 m

Registered L x B x D

175,00 x 32,20 x 18,40 m

Freeboard

5.514 mm

Depth

18,40 m moulded

Speed

15,2 knots

Built

2010

Keel laid

21.01.2010

Launch date

27.03.2010

Date of completion

22.07.2010

Builder

Onomichi Dockyard Co., Ltd.
Onomichi
Japan

Yard number

553

Hull material

Steel

Hull type

Double hull

Main engine

1x MAN-B&W/Mitsui 6S50MC - 2 stroke single acting 6 cylinder 500 x 1.910 mm diesel engine - 8.580 kW / 11.640 hp at 127,0 rpm

Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. TAMANO Shipyard

Propeller shaft

1x Oil lubrication shaft with monitoring device

Diameter: 520 mm

Propellers

1

Boilers

1x Auxiliary vertical boiler - 17,7 bar

Evaporation: 26,62 t/h

Manufacturer: Aalborg (Qingdao) Boiler Company Ltd.

Generators

4x Generators - 1.950 kVA

Number of cargo tanks

14

Cargo tank capacity

55.457 m³

Tank capacities

Fuel oil: 1.701 m³

fresh water: 445 m²

Water ballast: 18.458 m³

Manager

Anglo Eastern Shipmanagement Singapore Pte. Ltd.
Republic of Singapore

Registered owner

Wega Navigation Corporation Limited

Latest data adjustment

02 March 2015
