Westerschelde 31 May 2019 |
 |
 |
 |
 |
 |
 |
|||||
| Antwerpen 06/12/14 | Westerschelde 05/01/19 | Westerschelde 05/05/17 | Westerschelde 19/12/15 | Westerschelde 19/12/15 | Westerschelde 19/12/15 | |||||
|
Name |
STOLT AUK |
|
Previous names |
2001 - 06/2011 Trans Alina 06/2011 - 01/2012 NST Alina 01/2012 - 01/2014 Alina |
|
Type |
Tank for oil and chemicals |
|
IMO-number |
9164108 |
|
Call sign |
2HLY2 |
|
Flag |
United Kingdom |
|
Port of registry |
Cardiff |
|
GT |
3.441 t |
|
DWT |
5.064 t |
|
NT |
1.449 t |
|
Length |
99,35 m overall 94,06 m between perpendiculars |
|
Breadth |
15,33 m extreme |
|
Draught |
6,25 m |
|
Keel to mast end |
38,00 m |
|
Freeboard |
1.460 mm |
|
Depth |
7,70 m moulded |
|
Speed |
Service: 14,0 knots Max.:16,0 knots |
|
Built |
2001 |
|
Keel laid |
16/01/1998 |
|
Launch date |
20/01/2001 |
|
Date of completion |
12/04/2001 |
|
Builder |
Van Der Giessen De Noord B/V. Alblasserdam The Netherlands |
|
Yard number |
982 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 6R32 - 4 stroke single acting 6 cylinder 320 x 350 mm combustion engine Mcr 2.260 kW / 3.073 hp at 750 rpm Built: 2000 Builder: Wärtsilä Nederland B.V., Zwolle - The Netherlands |
|
Propellers |
1x Screw propeller controllable pitch - aft at 94,0 rpm |
|
Boilers |
1x CHO Wiesloch 20,00 m² - 13,0 bar 1x CHR WIesloch 10,00 m² - 13,0 bar 1x CHO Wiesloch 10,00 m² - 13,0 bar |
|
Bow thruster |
1x 300 kW |
|
Electric installations |
Power voltage: 440 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Shaft generator |
1x 672 kVA - 538 kW / 440 Volt |
|
Generators |
3x Caterpillar 3412C - 4 stroke 12 cylinder 137 x 152 mm diesel engine each Mcr 534 kW connected with generators each 496 ekW / 620 kVA - 440/220 Volt 50 Hz |
|
Bow thruster |
1x 300 kW |
|
Number of tanks |
14 |
|
Cargo tank capacity |
5.064 m³ |
|
Number of pumps |
15x Cargo pumps each 120 m³/h |
|
Tank capacities |
Fuel: 335,6 m³ |
|
Manager |
Stolt Tankers B.V. Haven 190, Westerlaan 5 3016 CK Rotterdam The Netherlands |
|
Operator |
Stolt Tankers BV |
|
Owner |
Stolt-Nielsen Inter-Europe Service (SNIES) |
|
Registered owner |
Stolt Auk BV Care of Stolt Tankers BV Westerlaan 5 3016 CK Rotterdam The Netherlands |
|
Latest data adjustment |
09 August 2021 |
