Deurne, Belgium 18 January 2014 |
|
Name |
STEFFI |
|
Type |
Inland tanker |
|
ENI-number |
04809690 |
|
Call sign |
DF7037 |
|
Flag |
Germany |
|
Port of registry |
Hamburg |
|
DWT |
1.692,54 t |
|
Length |
84,85 m |
|
Breadth |
9,50 m overall |
|
Draught |
3,20 m |
|
Depth |
4,57 m moulded |
|
Built |
2011 |
|
Keel laid |
25.02.2011 |
|
Launch date |
22.02.2011 |
|
Date of completion |
09.09.2011 |
|
Builder |
Groningen Shipyard B.V. |
|
Yard number |
125 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double hull Partly double bottom |
|
Watertight bulkheads |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x Caterpillar 3508 (B) DI-TA electronic 4 stroke 12 cylinder 145 x 162 mm diesel engine - 746 kW / 1.014 hp at 1.800 rpm Year of manufacture: 2008 Manufacturer: Caterpillar, Inc. |
|
Gearbox |
1x Masson Marine type MM W4400 Reduction: 5,077:1 |
|
Propellers |
1x Solid 5 bladed propeller at 355 rpm diameter 1.550 mm with Van de Giessen Optima nozzle diameter 1.566 mm |
|
Electric installations |
1x Plant 400 V - 435 kVA 1x Plant 400 V - 63 kW 1x Plant 400 V - 120 kW |
|
Generators |
1x Generator 435 kVA 1x Generator 120 kW 1x Generator 63 kW |
|
Bow thruster |
1x Transverse thruster Volvo Penta - Verhaar Omega - 385 hp / 282 kW at 1.780 rpm |
|
Total tank capacity |
1.763 m³ |
|
Cargo pumps |
2x Bornemann cargo pumps type W7T each 300 m³/h couples with electro-motor each 125 kW |
|
Manager |
FB Schifffahrt GmbH & Co. KG |
|
Owner |
Alster Capital GmbH & Co. |
|
Registered owner |
TMS "STEFFI" Schiffahrtsgesellschaft mbH & Co. KG |
|
Latest data adjustment |
01 March 2014 |
