| Vlissingen, The Netherlands 18 November 2012 |
 |
| Vlissingen 18/11/12 |
|
Name |
THEO T |
|
Type |
Crude oil tanker |
|
IMO-number |
9262194 |
|
Call sign |
C6SY5 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
40.013 t |
|
DWT |
Summer: 73.021,2 t |
|
NT |
20.903 t registered Panama: 33.077 t |
|
Length |
227,28 m overall 220,60 m between perpendiculars |
|
Breadth |
32,24 m moulded |
|
Keel to masthead |
47,23 m |
|
Freeboard |
Summer: 6.219 mm Winter: 6.511 mm Tropical: 5.927 mm |
|
Depth |
20,24 m moulded |
|
Speed |
14,5 knots |
|
Built |
2003 |
|
Keel laid |
11.03.2003 |
|
Launch date |
17.05.2003 |
|
Date of completion |
06.08.2003 |
|
Builder |
Samsung Shipbuilding & Heavy Industries Co., Ltd. |
|
Yard number |
1407 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Bulkheads |
Water tight: 13 Oil tight: 2 |
|
Main engine |
1x B&W 6S60MC - 6 cylinder 600 x 2.292 mm diesel engine - 10.370 kW at 89,0 rpm Manufacturer: HSD Engine Co.,Ltd. |
|
Propellers |
1 |
|
Boilers |
1x Exhaust gas boiler Manufacturer: Kangrim Ind.,Ltd. 2x Auxiliary oil fired boiler Heating surface: each 110 m² Manufacturer: Aalborg Industries Ltd. |
|
Generators |
3x Main diesel generatorsets HFC6 508-84E-OY each 690 kW Manufacturer: Hyundai Heavy Ind., Co., Ltd. |
|
Number of cargo tanks |
14 |
|
Cargo tank capacity 98% |
Seg#1: 25.476,7 m³ Seg#2: 26.250,2 m³ Seg#3: 28.258,5 m³ Total 98%: 75.740 m³ ex slop tanks Total 100%: 8.1618 m³ / 79.985,64 t |
|
Slop tanks 98% |
4.142 t |
|
Pumps |
Cargo: 5x Centrifugal each 2.000 m³/h Ballast: 2x Electric each 1.000 m³/h |
|
Manifolds |
Stern to centre manifold: 106,00 m Distance bridge front to centre of manifold: 83,00 m Distance between cargo manifold centres: 2.500 mm Distance ships rail to manifold: 4.360 mm Distance manifold to ships side: 4.600 mm Top of rail to centre of manifold: 1.100 mm Distance main deck to centre of manifold: 2.100 m |
|
Number of tanks |
Ballast: 14 Lubricating oil: 7 Fuel oil: 7 Fresh water: 4 Diesel oil: 2 Chain: 2 Sludge: 2 Waste water: 1 |
|
Tank capacities |
Diesel oil: 181,7 m³ / 163,53 t Fresh water: 247,5 m³ Fuel oil: 2.656,5 m³ / 2.603,37 t Lube oil: 90,1 m³ / 81,09 t Tank ballast: 29.335,4 m³ / 30.068,78 t |
|
Lifting equipment |
1x Engine room crane MSB-3.2 - SWL 3,2 t Manufacture: Oriental Precision & Eng., Co., Ltd. 1x Hose handling crane GPH 500-1521 - SWL 15,0 t Manufacture: Samsung Marine Tech. 1x Provision crane - SWL 3,2 t 1x Provision crane - SWL 1,0 t Manufacture: Dongwoo Machinery & Engineering Co.,Ltd. |
|
Manager |
Afinity Maritime, S.A. |
|
Operator |
Ionia Management, S.A. |
|
Owner |
Afinity Maritime, S.A. |
|
Registered owner |
Afinity Maritime S.A |
|
Last update |
18 July 2013 |
