Zuidwal 02
02 September 2010



Name

ZUIDWAL

Type

Inland oil tanker

ENI-number

02333788

Flag

The Netherlands

Port of registry

Zwijndrecht

DWT

2.750 t

Length

110,00 m

Breadth

11,45 m

Draught

3,35 m

Depth

4,60 m

Built

2010

Builder

Shipyard Begej
Zrenjanin
Serbia

Yard number

288

Hull type

Double hull coated

Main engine

1x ABC 6 (M)DZC-1000-166 - 1.326 kW / 1.800 hp at 1.000 rpm

Builder: Anglo Belgian Corporation N.V.
Wiedauwkaai 43
Gent
Belgium

Steering gear

Hydraulic, make Promac

Generator

1x Caterpillar C18 ACERT diesel engine coupled with a Marathon 572 RSL 4030 generator 525 kVA

1x Perkins 4.4 TW2GM diesel engine coupled with Marathon 363 CSL 1607 generator 107 kVA

1x Perkins 4.4 TWGM diesel engine coupled with Marathon 362 CSL 1606 generator 85 kVA

Bow thruster

1x Verhaar Omega 31120-4k - 375 kW / 1.780 rpm diesel electric driven a Promarin 5-Blades, diameter 1.750 mm screw

Cargo capacity

3.040 m³

Number of tanks

8x Cargo tanks - 380 m³ with Hempel zinc silicate coating

Pumps

8x Marflex deepwell pumps each 100 m³ at 60,0 rpm

Accommodation aft ship

1x living room

1x kitchen

2x bath rooms

5x bedrooms

Manager

Interstream Barging B.V.
Centraleweg 9
4931 NA Geertruidenberg
The Netherlands

Operator

Mercurius Scheepvaart Group
Ringdijk 466 C
NL-3331 LK Zwijndrecht
The Netherlands

Owner

VNC Binnenvaart IV C.V.
Groningen
The Netherlands
