| Westerschelde 09 March 2020 |
 |
 |
 |
 |
 |
||||
| Westerschelde 06/08/17 | Westerschelde 06/08/17 | Westerschelde 28/12/12 | Westerschelde 01/04/16 | Vlissingen 20/01/17 | ||||
|
Name |
WILLY |
|
Type |
Tanker for oil & chemicals |
|
IMO-number |
9268241 |
|
Call sign |
ZDFW5 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
GT |
4.973 t |
|
DWT |
Summer: 7.428 t |
|
NT |
2.241 t |
|
Length |
106,13 m overall 102,09 m registered |
|
Breadth |
16,50 m registered |
|
Draught |
7,44 m |
|
Keel to mast end |
30,00 m |
|
Depth |
10,60 m |
|
Speed |
13,2 knots |
|
Keel laid |
28/06/2002 |
|
Launch date |
24/05/2003 |
|
Date of completion |
24/08/2003 |
|
Builder |
Sedef Gemi Insaati A.S. Tersaneler Yolu No:14 Tuzla 81700 Istanbul Turkey |
|
Yard number |
125 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double hull Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
9 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M32 C - 4 stroke 6 cylinder 320 x 480 mm combustion engine 2.880 kW / 3.916 hp at 600 rpm Year of manufacture: 2002 Manufacturer: Caterpillar Motoren GmbH & Co. KG Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 148 rpm |
|
Boilers |
1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 64,9 m² 2x Thermal oil heater, oil fired - 10,0 bar Heating surface: 64,3 m² Year of manufacture: 2002 Manufacturer: Wiesloch Marine & Industries B.V. Ohmweg 8 3208 KE Spijkenisse The Netherlands |
|
Electric installations |
3x Plant each 440/220 V - 600 kVA 1x Plant 440 V - 688 kVA 1x Plant 440 V - 124 kVA |
|
Shaft generator |
1x 688 kVA |
|
Generators |
3x Main diesel generatorsets each 600 kVA |
|
Emergency generator |
1x Diesel generatorset 124 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar 1x Receiver 150 litres - 30,0 bar 1x Receiver 1.000 litres - 10,0 bar 1x Receiver 500 litres - 10,0 bar |
|
Bow thruster |
1x Transverse thruster JASTRAM - 390 kW, forward |
|
Number of cargo tanks |
14 |
|
Cargo tank capacity |
9.199 m³ |
|
Number of pumps |
10x Cargo pumps each 200 m³/h 4x Cargo pumps each 100 m³/h |
|
Tank capacities |
Fuel: 483 m³ Ballast water: 3.072 m³ |
|
Anchor equipment |
3x Anchors weight each 2.850 kg Chain length: 495,00 m Diameter: 42 mm |
|
Crew size |
16 |
|
ISM & commercial manager |
Carl F. Peters (GmbH & Co.) KG Kurze Mühren 13 20095 Hamburg Federal Republic of Germany |
|
Registered owner |
Silverwood Shipping Co. Ltd. c/o Carl F. Peters (GmbH & Co.) KG Kurze Mühren 13 20095 Hamburg Federal Republic of Germany |
|
Latest data adjustment |
24 June 2022 |
