| Westerschelde 30 November 2011 |
 |
| Westerschelde 30/11/11 |
|
Name |
VALLE DI SIVIGLIA |
|
Previous names |
Valle De Siviglia |
|
Type |
Chemical / Oil Products tanker |
|
IMO-number |
9220938 |
|
Call sign |
ITBN |
|
Flag |
Italy |
|
Port of registry |
Trieste |
|
GT |
25.063 t |
|
DWT |
Summer: 40.218 t |
|
NT |
10.189 t |
|
Length |
175,93 m overall 169,62 m between perpendiculars |
|
Breadth |
31,00 m moulded |
|
Draught |
9,00 m |
|
Freeboard |
5.913 mm |
|
Depth |
17,00 m moulded |
|
Speed |
15,0 knots |
|
Built |
2001 |
|
Date of completion |
06.09.2001 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. |
|
Yard number |
9926 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai-B&W - 2 stroke single acting 6 cylinder 500 x 1.910 mm diesel engine - 8.580 kW / 11.658 hp at 127 rpm Built: 2001 Builder: Hyundai Heavy Ind. Co., Ltd. - Engine & Mach. Div, Ulsan - South Korea |
|
Propeller |
1x Screw propeller solid - at 127 rpm |
|
Boilers |
1 CHO Aalborg - 7,0 bar 1 CHR Aalborg - 7,0 bar |
|
Diesel generators |
3x Main diesel generatorsets each 900 kVA - 720 kW - 1.045 hp |
|
Emergency diesel generator |
1x Diesel generatorset 131 kVA - 105 kW - 136 hp |
|
Bow thruster |
1.000 kW |
|
Number of cargo tanks |
15 |
|
Total capacity of tanks |
44.589,3 m³ |
|
Slop tank |
1.700 m³ |
|
Recovery tank |
370 m³ |
|
Cargo handling |
12x Submerged centrifugal hydraulic driven pumps each 450 m³/h 2x Submerged centrifugal hydraulic driven pumps each 100 m³/h 1x Submerged centrifugal hydraulic driven pump 70 m³/h |
|
Fuel Capacity |
1.453,7 m³ |
|
Manager |
Montanari Navigazione |
|
Operator |
Navigazione Montanari S.p.A. |
|
Owner |
Montanari Navigazione |
