Sten Moster - IMO 9341184

Name

STEN MOSTER

Type

Tanker for oil and chemicals

IMO-number

9341184

Call sign

ZDHG3

Flag

Gibraltar

Previous flags

2006 - 2006 Norway

Port of registry

Gibraltar

GT

11.935 t

DWT

16.670 t

NT

5.141 t

Length

144,05 m overall

134,43 m between perpendiculars

Breadth

23,19 m extreme

Draught

8,90 m

Keel to top of mast

44,50 m

Depth

12,40 m

Speed

14,0 knots

Built

2006

Keel laid

05.12.2004

Launch date

26.08.2005

Date of completion

21.04.2006

Builder

Jiangnan Shipyard (Group) Co., Ltd.
Feng Chan Village, Chang Xing Town Chongmin County
Shanghai
China

Yard number

H2351

Hull material

Steel

Hull type

Double hull

Bulkheads

Trans. Bulkheads: 8

Long. Bulkheads: 1

Main engine

1x Wärtsilä 6L46C - 6 cylinder diesel engine - 6.300 kW at 500 rpm

Builder: Wärtsilä Finland Oy

Propellers

1x Controllable pitch - 4 blades

Builder: Wärtsilä Propulsion Norway AS

Boilers

Auxiliary boiler, vertical shell AQ-9

Auxiliary boiler, composite AQ-16

Builder: Aalborg Industries A/S

Shaft generator

1x AVK - 1.500 KW

Generators

1x Wärtsilä 6L20 diesel generatorset

2x Wärtsilä 4L20 diesel generatorsets

total capacity 2.280 kW at 900 rpm

Builder: Wärtsilä Finland Oy

Emergency generator

1x Sisu 634 diesel generatorset

Builder: Sisu Diesel Inc.

Bow thruster

1x Brunvoll - 800 kW

Number of cargo tanks

12

Capacity 98%: 18.491 m³

Number of slop tanks

3

Capacity 98%: 981 m³

Total cargo tank capacity 98%

19.172 m³

Number of segregations

8

Pumps

12x Framo each 300 m³/h

2x Framo 150 m³/h + portable pump

Pumping capacity

2.200 m³/h

Heating capacity

70°C

Ballast capacity

8.179 m³

Manifolds

Box to centre of manifold: 71,80 m

Lifting equipment

1x Hose crane - SWL 5,0 t

Manager

Rederiet Stenersen A/S
Solheimsgaten 13
N-5058 Bergen
Norway

Operator

Rederiet Stenersen AS

Registered owner

Stentank AS
Solheimsviken
N-5824 Bergen
Norway

Latest data adjustment

26 Januany 2015
