| Westerschelde 27 October 2018 |
 |
 |
 |
||
| Westerschelde 13/07/12 | Westerschelde 13/07/12 | Westerschelde 04/12/11 | ||
|
Name |
SEATURBOT |
|
Type |
Oil Tanker with double hull |
|
IMO-number |
9204764 |
|
Call sign |
DDTS |
|
Flag |
Germany |
|
Port of registry |
Bremen |
|
GT |
21.353 t |
|
DWT |
32.230 t |
|
NT |
7.591 t |
|
Length |
177,69 m overall 169,70 m registered |
|
Breadth |
28,00 m |
|
Draught |
11,00 m |
|
Forecastle |
14,20 m |
|
Freeboard |
5.815 mm |
|
Depth |
16,80 m moulded |
|
Speed |
16,0 knots |
|
Built |
2000 |
|
Keel laid |
14.07.1999 |
|
Launch date |
26.02.2000 |
|
Date of completion |
28.06.2000 |
|
Builder |
Lindenau GmbH Schiffswerft & Maschinenfabrik in Insolvenz Christianspries 30 24159 Kiel Federal Republic of Germany |
|
Yard number |
241 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN B&W 6 L 58/64 - 4 stroke 6 cylinder 580 x 640 mm diesel engine - 8.340 kW at 428 rpm Year of manufacture: 2000 Manufacturer: MAN B&W Diesel GmbH Stadtbachstr. 1 86153 Augsburg Federal Republic of Germany |
|
Propeller |
1x Controllable pitch propeller - aft at 121 rpm |
|
Boilers |
1x Steam boiler, exhaust gas heated - 12,0 bar Heating surface: 78,0 m² 1x Steam boiler, oil fired - 12,0 bar Heating surface: 125,0 m² Year of manufacture: 2000 Manufacturer: Alfa Laval Aalborg A/S Gasvaerksvej 24 9100 Aalborg Kingdom of Denmark |
|
Electric installations |
3x Plant 380/220 V each 1.200 kVA 1x Plant 380 V - 1.200 kVA 1x Plant 380 V - 200 kVA |
|
Shaft generator |
1x 1.200 kVA |
|
Generators |
3x Main diesel generatorsets each 1.200 kVA |
|
Emergency generator |
1x Diesel generatorset 200 kVA |
|
Bow thruster |
1x Fixed pitch propeller KAMEWA - 1.050 kW, forward |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 30,0 bar 1x Receiver 1.000 litres - 10,0 bar |
|
Number of cargo tanks |
12 |
|
Cargo capacity |
37.761 m³ |
|
Tank capacities |
Fuel oil: 863 m³ Ballast water: 17.136 m³ |
|
Anchor equipment |
3x Anchors weight each 7.350 kg Chain length: 605,00 m |
|
Manager |
German Tanker Shipping GmbH & Co. KG Hans-Böckler-Str. 50 28217 Bremen Federal Republic of Germany |
|
Operator |
German Tanker Shipping |
|
Owner |
TMS "Seaturbot" GmbH & Co. KG Hans-Böckler-Str. 50 28217 Bremen Federal Republic of Germany |
