Biberach - ENI 04003980

Name

BIBERACH

Type

Inland tanker

ENI-number

04003980

Call sign

DA4208

Flag

Germany

Port of registry

Stuttgart

Tonnage

1.383,230 t

Length

84,95 m

Breadth

8,99 m overall

Draught

1,83 m

Depth

2,70 m moulded

Built

1970

12.1986 Ship lengthened

Launch date

13.11.1970

Builder

Heinrich Grube Schiffswerft
Oortkatenufer 4
21037 Hamburg
Federal Republic of Germany

Yard number

196

Hull material

Steel

Watertight bulkheads

6

Continuous decks

1

Main engine

1x MWM TD 484-6 U - 4 stroke 6 cylinder 320 x 480 mm diesel engine - 589 kW / 800 hp at 375 rpm

Year of manufacture: 1970

Manufacturer: Motoren-Werke Mannheim AG
Carl-Benz-Str. 5
68167 Mannheim
Federal Republic of Germany

Propellers

1x Solid propeller - aft

Electric installations

1x Plant 380/220 V - 192 kVA

1x Plant 24/220 V - 1,5 kW

1x Plant 24/220 V - 2,5 kW

Generators

1x Main generator 192 kVA

1x Generator 2,5 kW

1x Generator 1,5 kW

Compressed air receivers

2x Receivers each 500 litres - 30,0 bar

1x Receiver 250 litres - 30,0 bar

Bow thruster

1x Omega jet - 135 kW, forward

Number of cargo tanks

5

Manager

WIJGULA Wijnhoff & van Gulpen & Larsen B.V.
Waalbandijk 123
6651 KB Druten
The Netherlands

Owner

Christian Groll
Dr.-Hammacher-Str. 2b
47119 Duisburg
Federal Republic of Germany

Previous owner

Lehnkering GmbH
Duisburg
Germany

Latest data adjustment

07 September 2015
