| Westerschelde 10 March 2018 |
 |
 |
|
| Westerschelde 10/03/18 | Westerschelde 10/03/18 | |
|
Name |
ENSEMBLE |
|
Type |
Oil/Chemical carrier |
|
IMO-number |
9749453 |
|
Call sign |
9V5144 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GRT |
21.316 t |
|
DWT |
Summer: 35.058 t |
|
NRT |
9.867 t |
|
Light displacement |
9.794 t |
|
Length |
179,53 m overall |
|
Breadth |
27,40 m moulded |
|
Draught |
Summer: 11,61 m |
|
Moulded L x B x D |
172,00 x 27,40 x 16,30 m |
|
Registered L x B x D |
172,99 x 27,40 x 16,30 m |
|
Keel to mast end |
43,33 m |
|
Freeboard |
Summer: 4.728 mm |
|
Depth |
16,30 m moulded |
|
Speed |
Max: 15,8 knots Services: 14,0 knots |
|
Build |
2017 |
|
Keel laid |
01/12/2015 |
|
Launch date |
12/04/2017 |
|
Date of completion |
25/10/2017 |
|
Builder |
Shin Kurushima Dockyard Co. Ltd. Imabari Japan |
|
Yard number |
5901 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
2x MAN-B&W 6S46ME-B8 - 2 stroke single acting 6 cylinder 460 x 1.932 mm combustion engine Mcr 5.800 kW / 7.886 hp at 110,0 rpm Ncr 4.930 kW / 6.702 hp at 104,0 rpm Manufacturer: Makita Corporation - Japan |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 510 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 0,98 MPa Evaporation: 19,12 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 1.000 kVA at 720 rpm |
|
Number of tanks |
28 |
|
Cargo tank capacity |
Liquid: 37.591 m³ |
|
Number of pumps |
14x Cargo pumps each 330 m³/h 14x Cargo pumps each 200 m³/h 2x Hydraulic driven, vertical centrifugal ballast pumps each 650 m³/h |
|
Tank capacities |
Fuel: 1.564,48 m³ Diesel oil: 136,85 m³ Fresh water: 676,71 m³ Ballast: 12.117,39 m³ |
|
Accommodation |
Officer: 8 Crew: 15 Other: 7 Total: 30 |
|
Commercial manager |
MOL Chemical Tankers Pte. Ltd. 15-01, UIC Building, 5, Shenton Way Singapore 068808 Republic of Singapore |
|
ISM manager |
Unix Line Pte. Ltd. 15-01, UIC Building, 5, Shenton Way Singapore 068808 Republic of Singapore |
|
Registered owner |
MOL Chemical Tankers Pte. Ltd. 15-01, UIC Building, 5, Shenton Way Singapore 068808 Republic of Singapore |
|
Latest data adjustment |
16 September 2024 |
