Name |
SONGA PEACE |
|
Previous names |
2009 - 12/2013 Global Peace |
|
Type |
Chemical and oil product tanker |
|
IMO-number |
9409522 |
|
Call sign |
V7CY5 |
|
Flag |
Marshall islands |
|
Port of registry |
Majuro |
|
Previous flags |
2009 - 2013 Hong Kong - Call sign: VRFP3 |
|
GT |
11.623 Suez: 12.487,44 t t |
|
DWT |
Summer: 19.992,70 t Winter: 19.411,91 t |
|
NT |
6.056 t Suez: 11.033,42 t Panama: 9.779 t |
|
Displacement |
Summer: 25.290,70 t Winter: 24.719,51 t |
|
Length |
145.53 m overall |
|
Breadth |
23,70 m extreme |
|
Draught |
Summer: 9,71 m Winter: 9,51 m |
|
Reg. dimensions L x B x D |
137,92 x 23,70 x 13,35 m |
|
Rule dimensions L x B x D |
137,00 x 23,70 x 13,35 m |
|
Keel to mast end |
37,24 m |
|
Air draft |
Summer deadweight: 27,50 m Normal ballast: 31,29 m Lightship: 34,98 m |
|
Freeboard |
Summer: 3.670 mm Winter: 2.870 mm |
|
Depth |
13,35 m moulded |
|
Speed |
Ballast: Max: 15,3 knots - Economic: 12,5 knots Laden: Max: 11,5 knots - Economic: 12,0 knots |
|
Built |
2009 |
|
Keel laid |
15/06/2009 |
|
Launch date |
26/08/2009 |
|
Date of completion |
05/11/2009 |
|
Builder |
Usuki Shipyard Co. Ltd. Usuki Japan |
|
Yard number |
USCL1718 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
Transverse: 14 |
|
Continuous decks |
1 |
|
Main engine |
1x Hitachi/MAN-B&W 6S42MC - 2 stroke single acting 6 cylinder 420 x 1.764 mm combustion engine 6.150 kW at 136,0 rpm Build: 06/2009 Builder: Hitachi Zosen Corporation, Onomichi - Japan |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary water tube boiler - 9 kg/cm² Heating surface: 184,2 m² 2x Economizer EGE - 14,0 kg/cm² Heating surface: 129,9 m² Build: 05/2009 Builder: Miura Co., Ltd., Matsuyama - Japan |
|
Generators |
3x Yanmar main diesel generatorsets each 575 kVA / 450 Volt |
|
Bow thruster |
1x 666 kW / 830 bhp |
|
Number of cargo tanks |
20 |
|
Capacity (98%) of each natural segregation |
Seg#1: 700,004 m³ (1P) Seg#2: 706,629 m³ (1S) Seg#3: 1.234,963 m³ (2p) Seg#4: 1.234,363 m³ (2S) Seg#5: 1.231,928 m³ (3p) Seg#6: 1.222,240 m³ (3S) Seg#7: 713,791 m³ (4P) Seg#8: 719,806 m³ (4S) Seg#9: 1.254,717 m³ (5p) Seg#10: 1.264,582 m³ (5S) Seg#11: 1.254,840 m³ (6P) Seg#12: 1.264,211 m³ (6S) Seg#13: 1.254,466 m³ (7P) Seg#14: 1.264,211 m³ (7S) Seg#15: 628,480 m³ (8P) Seg#16: 628,93 m³ (8S) Seg#17: 1.261,55 m³ (9P) Seg#18: 1.252,91 m³ (9S) Seg#19: 1.206,98 m³ (10P) Seg#20: 1.197,60 m³ (10S) Seg#21: 347,16 m³ (11P) Seg#22: 344,31 m³ (11S) |
|
Cargo tank capacity 98% |
Liquid: 21.497 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
691,47 m³ |
|
Pumps |
14x Centrifugal cargo pumps each 300 m³/h 8x Centrifugal cargo pumps each 200 m³/h 1x Emergency pump 70 m³/h 2x Centrifugal ballast pump each 300 m³/h |
|
Manifolds |
Distance bridge front to centre of manifold: 46,74 m Bow to centre manifold: 72,38 m Stern to centre manifold: 73,25 m Distance between cargo manifold centres: 380 mm Distance ships rail to manifold: 4.300 mm Distance manifold to ships side: 4.300 mm Top of rail to centre of manifold: 505 mm Distance main deck to centre of manifold: 2.650 mm Spill tank grating to centre of manifold: 850 mm |
|
Tank capacities |
Fuel oil: 872,6 m³ Diesel oil: 146,8 m³ Fresh water: 663,8 m³ Water ballast: 7.785,7 m³ |
|
Lifting equipment |
1x Crane - SWL 5,0 t |
|
Crew |
22 |
|
Manager |
Songa Shipmanagement Ltd. 2, Marchfield Drive Paisley, PA3 2RB United Kingdom |
|
Technical operator |
Songa Shipmanagement Ltd. 2, Marchfield Drive Paisley, PA3 2RB United Kingdom |
|
Commercial operator |
Hansa Tankers AS Kalfarveien 57A 5022 Bergen Norway |
|
Registered owner |
Songa Chemical AS Haakon VIIs gate Oslo Norway |
|
Disponent owner |
Hansa Tankers AS Kalfarveien 57A 5022 Bergen Norway |
|
Group |
The Blystad Group Haakon VIIs gate Oslo Norway |
|
Previous names & owners |
2009 - 12/2013 Global Peace - Heroic Lepus Inc. |
|
Latest data adjustment |
08 November 2020 |
