Vlissingen, The Netherlands 18 May 2018 |
|
Name |
KATELINA |
|
Previous names |
Build as: OW Kattegat 2014 - 09/2014 Kateline 09/2014 - 01/2015 Orakate |
|
Type |
Chemical tanker |
|
IMO-number |
9485368 |
|
Call sign |
ZDOA7 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
Previous flags |
2014 - 08/2014 Cyprus, Limassol - Call sign: 5BWV3 |
|
GT |
6.382 t |
|
DWT |
Summer: 8.933,05 t |
|
NT |
2.733 t |
|
Length |
118,16 m overall 110,98 m between perpendiculars |
|
Breadth |
18,63 m extreme 18,50 m moulded |
|
Draught |
Summer: 7,90 m Ballast: 5,10 m |
|
Height from keel to mast |
37,60 m |
|
Air draft |
Ballast: 32,50 m Loaded: 29,70 m |
|
Depth |
10,00 m moulded |
|
Speed |
Max: 14,5 knots |
|
Built |
2014 |
|
Keel laid |
28/12/2009 |
|
Launch date |
14/11/2011 |
|
Date of completion |
23/05/2014 |
|
Builder |
CSC Nanjing Tanker Corporation Zijinshan Shipyard China |
|
Yard number |
SP0702 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
2x MaK 6M25 - 6 cylinder combustion engine each 1.980 kW Builder: Caterpillar Motoren GmbH & Co. KG |
|
Propellers |
2x Controllable pitch propellers |
|
Boilers |
1x Auxiliary boiler, composite 1x Auxiliary boiler, oil/gas fired |
|
Generators |
2x Hyundai/Himsen 5H17/28 - 4 stroke 5 cylinder 170 x 280 mm each 600 kW connected with generator 575 kW |
|
Emergency generator |
1x Cummins 6CTA8.3-D(M) diesel generatorset 180 kW |
|
Bow thruster |
1x 450 kW |
|
Number of cargo tanks |
10 |
|
Number of segregations |
10x Double valves |
|
Cargo tank capacity 98% |
9.360,36 m³ |
|
Slop tank capacity 98% |
143,98 m³ |
|
Pumps |
2x Centrifugal deepwell cargo pumps each 500 m³/h 4x Centrifugal deepwell cargo pumps each 400 m³/h 2x Centrifugal deepwell cargo pumps each 80 m³/h 2x ballast pumps each 450 m³/h |
|
Manifolds |
Distance from bow to centre manifold: 57,70 m Distance from stern to centre manifold: 60,50 m Distance between manifolds: 1,00 m Distance from ship side to manifold: 4,10 m |
|
Tank capacities |
Ballast: 3.914 m³ |
|
Anchor equipment |
Length: 522,50 m Diameter: 48 mm |
|
Lifting equipment |
2x Cranes - SWL 4,0 t |
|
Crew size |
14 |
|
Manager |
South End Tanker Management BV Aventurijn 218 3316 LB Dordrecht The Netherlands |
|
Operator |
Uni-Tankers Turbinevej 10 DK-5500 Middelfart Denmark |
|
Registered owner |
Kate Shipping Ltd. Care of South End Tanker Management BV Aventurijn 218 3316 LB Dordrecht The Netherlands |
|
Latest data adjustment |
04 September 2020 |
