Westerschelde 25 May 2016 |
 |
 |
|
| Westerschelde 21/06/18 | Westerschelde 30/08/20 | |
|
Name |
SELENE PRAHM |
|
Type |
Multi-purpose cargo ship |
|
IMO-number |
9100059 |
|
Call sign |
DCNG |
|
Flag |
Germany |
|
Port of registry |
Leer |
|
GT |
1.584 t |
|
DWT |
Summer: 2.422 t |
|
DWCC |
Summer: 2.200 t Winter: 2.150 t |
|
NT |
878 t |
|
Lightship |
812 t |
|
Length |
75,10 m overall 70,20 m between perpendiculars |
|
Breadth |
11,65 m extreme |
|
Draught |
Max: 4,38 m 3,10 m ballast |
|
Air draft |
18,60 m |
|
Forecastle |
5,40 m |
|
Depth |
6,70 m |
|
Speed |
10,7 knots |
|
Built |
1994 |
|
Keel laid |
17/05/1993 |
|
Delivery date |
17/05/1994 |
|
Date of completion |
25/06/1994 |
|
Builder |
Kötter Werft Gmbh Haren/Ems Germany |
|
Yard number |
88 |
|
Hull material |
Steel |
|
Movable bulkheads |
2x Movable bulkheads (12 positions) |
|
Continuous decks |
1 |
|
Main engine |
1x Alpha/MAN-B&W 6L23/30 A - 4 stroke single acting 6 cylinder 225 x 300 mm combustion engine 830 kW / 1.130 bhp at 900 rpm Build: 1993 Builder: MAN B&W Diesel A/S Frederikshavn - Denmark |
|
Propellers |
1x Controllable pitch propeller |
|
Electric installations |
380/220 Volt - 50 Hz |
|
Shaft generator |
1x 230 kW |
|
Generators |
1x Deutz/MWM TD 226-6 - 6 cylinder 105 x 120 mm diesel engine 120 kW at 1.500 rpm connected with generator 67 kW Build: 1993 |
|
Emergency generator |
1x Deutz/MWM F5 L912 diesel generatorset 34 kW |
|
Bow thruster |
150 kW |
|
Number of holds |
1 49,20 x 9,30 x 6,64 m |
|
Cargo hold capacity |
Grain & Bale: 110.000 ft³ / 2.832 m³ |
|
Timber capacity |
3.00 m³ |
|
Number of hatches |
1 49,20 x 9,30 m |
|
Type hatch cover |
Folding covers |
|
Max permitted loads |
Tanktop: 12,0 t/m² Hatch covers: 1,2 t/m² |
|
Tank capacities |
Ballast: 1.067,74 m³ |
|
Anchor equipment |
Length: 389,20 m Diameter: 28 mm |
|
Commercial manager |
Karl Meyer Reederei GmbH & Co. KG Stader Str. 55-63 21737 Wischhafen Germany |
|
ISM manager |
Hammann & Prahm Reederei GmbH Stader Str. 55-63 21737 Wischhafen Germany |
|
Registered owner |
Karl Meyer Reederei GmbH & Co. KG Stader Str. 55-63 21737 Wischhafen Germany |
|
Latest data adjustment |
04 November 2024 |
