Name
|
ARNEBORG
|
|
Previous names
|
2006 - 10/2010 Arneborg
10/2010 / 03/2011 Sloman Sprinter
|
|
Type
|
Multi-purpose cargo ship - Strengthened for heavy cargoes - Container cargoes in all holds and on upper deck and on all hatch covers
|
|
IMO-number
|
9333539
|
|
Call sign
|
PHHD
|
|
Flag
|
The Netherlands
|
|
Port of registry
|
Delfzijl
|
|
GT
|
11.864 t
|
|
DWT
|
Summer: 17.256 t
|
|
DWCC
|
Summer: 15.700 t
|
|
NT
|
5.650 t
|
|
Number of 20ft containers
|
962
|
|
Container capacity 14t
|
640
|
|
Reefer capacity
|
60
|
|
Length
|
143,00 m overall
133,36 m between perpendiculars
|
|
Breadth
|
21,50 m extreme
|
|
Draught
|
Summer: 9,69 m
Winter: 9,50 m
|
|
Air draft
|
35,40 m in ballast
|
|
Depth
|
13,30 m moulded
|
|
Speed
|
15,4 knots
|
|
Built
|
2006
|
|
Keel laid
|
28/04/2006
|
|
Launch date
|
11/08/2006
|
|
Date of completion
|
28/11/2006
|
|
Builder
|
Hudong Zhonghua Shipbuilding (Group) Co. Ltd.
Shanghai
China
|
|
Yard number
|
1363A
|
|
Hull material
|
Steel
|
|
Hull type
|
Single hull
|
|
Continuous decks
|
1
|
|
Main engine
|
1x Wärtsilä 8L46B - 4 stroke single acting 8 cylinder 460 x 580 combustion engine 7.800 kW at 500 rpm
Manufacturer: Wärtsilä Diesel Oy, Turku - Finland
|
|
Propellers
|
1 Wärtsilä propeller 4 blades - Diameter: 4.800 mm
|
|
Bow thruster
|
1x 750 kW
|
|
Number of holds
|
2x Fully box and double skinned
Hold 1: 35,80 x 17,75 x 13,50 m
Hold 2: 52,10 x 17,75 x 13,50 m
|
|
Cargo hold capacity
|
Grain/bale:
Hold 1: 269.401 ft³
Hold 2: 438.232 ft³
Total: 707.633 ft³
|
|
Hold ventilation
|
12x Electrical ventilations per hour basis empty holds
Both holds fitted with dehumidifier system
|
|
Number of hatches
|
2
Hatch 1: 35,80 x 17,75 m
Hatch 2: 52,10 x 17,75 m
|
|
Hatch type
|
MacGregor navire hydraulic steel pontoon hatches
|
|
Tween deck
|
Eequipped with a full tweendeck, consisting of loose tweendeck pontoons of each:
No. 1: 9,90 x 3,22 x 0,90 m weight abt. 6 tons
No. 2 + 3: 12,57 x 6,48 x 0,90 m weight abt. 25 tons
No. 4: 17,65 x 6,48 x 0,90 m weight abt. 33 tons
Tweendecks can be used as vertical bulkheads at every 20ft interval
|
|
Max permitted loads
|
Tanktop: 20,0 t/m²
Max pressure tweendeck 4,00 t/m²
Max pressure weatherdeck 1,75 t/m²
|
|
Tank capacities
|
HFO: 1.448 m³
MGO: 218 m³
Water ballast: 5.490 m³
Fresh water: 280 m³
|
|
Cargo gear
|
3x Liebherr deck cranes - SWL 60,0 t each
|
|
Manager
|
Wagenborg Shipping BV
Marktstraat 10
9934 CK Delfzijl
The Netherlands
|
|
Owner
|
Wagenborg Shipowners BV
Delfzijl
The Netherlands
|
|
Previous owners
|
11/2006 - 12/2008 Arneborg Limited B.V., Delfzijl - The Netherlands
|
|
Latest data adjustment
|
03 May 2021
|
