Westerschelde 28 January 2017 |
 |
| Westerschelde 28/01/17 |
|
Name |
NAVIN EAGLE |
|
Previous names |
Universe 3 Satine |
|
Type |
Bulk carrier |
|
IMO-number |
9485186 |
|
Call sign |
V7LW4 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
5.087 t |
|
DWT |
Summer: 7.390 t Winter: 7.157 t |
|
NT |
2.625 t |
|
Length |
112,80 m overall 106,00 m between perpendiculars |
|
Breadth |
17,20 m |
|
Draught |
6,90 m |
|
Depth |
9,10 m moulded |
|
Speed |
Max.: 15,0 knots |
|
Built |
2008 |
|
Keel laid |
2007 |
|
Date of completion |
15.05.2008 |
|
Builder |
Universe Shipbuilding (Yangzhou) Co Ltd - Yizheng JS Yard |
|
Yard number |
06-003 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Daihatsu 8DKM-28 - 4 stroke single actin 8 cylinder 280 x 390 mm diesel engine 2.500 kW / 3.399 hp at 750 rpm Builder: Shaanxi Diesel Heavy Industry Co., Ltd - China |
|
Propellers |
1x Fixed pitch propeller- aft at 178 rpm |
|
Generators |
3x Main diesel generatorsets each 250 kW |
|
Emergency generator |
1x Diesel generatorset 64 kW |
|
Number of holds |
3 |
|
Cargo hold capacity |
9.394 m³ |
|
Cargo gear |
2x Cranes - SWL 25,0 t each |
|
Crew size |
18 |
|
Operator |
Massoel |
|
Owner |
Bright Denizcilik ve Gemi İşletmeciliği A.Ş. |
|
Latest data adjustment |
23 June 2017 |
