Westerschelde 28 July 2018 |
 |
 |
|
| Antwerpen 22/05/17 | Antwerpen 22/05/17 |
|
Name |
CALAMAR |
|
Type |
General cargo ship - Equipped for carriage of containers - Equipped for carriage of dangerous goods |
|
IMO-number |
9528512 |
|
Call sign |
ZDKG6 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
GT |
2.779 t |
|
DWT |
Summer: 4.059 t |
|
DWCC |
Summer: 3.900 t Winter: 3.800 t |
|
NT |
1.384 t |
|
Number of 20ft containers |
In hold: 96 On deck 38 Total: 134 |
|
Length |
87,90 m overall 84,47 m between perpendiculars |
|
Breadth |
12,62 m overall |
|
Draught |
Summer: 5,67 m |
|
Air draft |
24,80 m (22,50 m with lowered aft mast) |
|
Depth |
6,10 m moulded |
|
Built |
2011 |
|
Date of completion |
12.2011 |
|
Builder casco |
Marine Projects Ltd. Shipyard |
|
Builder |
Bodewes Scheepswerf B.V Hoogezand |
|
Yard number |
706 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Movable bulkheads |
2 |
|
Continuous decks |
1 |
|
Main engine |
1x Mak 6M25 - 6 cylinder diesel engine 1.880 kW / 2.556 bhp at 750 rpm |
|
Propellers |
1x Controllable pitch propeller - 4 blades |
|
Shaft generator |
1x 264 kW |
|
Generators |
1x Main diesel generatorset 182 kW |
|
Bow thruster |
1x 220 kW |
|
Number of cargo holds |
1 61,95 x 10,30 x 8,98 m |
|
Cargo hold capacity |
Bale/grain: abt.: 5.605 m³ bulkheads ashore |
|
Hold ventilation |
Abt. 6 times/hour |
|
Number of hatches |
1 64,53 x 10,30 m |
|
Hatch type |
10x Pontoon steel hatch covers, lift away covers by a gantry crane |
|
Max. permitted loads |
Hatch covers: 1,60 t/m² Tween deck; 2,40 t/m² Tanktop: 13,0 t/m² |
|
Tank capacities |
IFO abt.: 180 m³ |
|
Crew size |
9 |
|
Manager |
ATOB@C Shipping |
|
Owner |
ATOB@C Shipping |
|
Latest data adjustment |
04 June 2017 |
