Westerschelde 03 October 2017 |
 |
 |
 |
 |
 |
 |
|||||
| Antwerpen 06/02/17 | Antwerpen 06/02/17 | Westerschelde 14/03/20 | Westerschelde 14/03/20 | Westerschelde 28/02/20 | Westerschelde 28/02/20 |
|
Name |
PATRON |
|
Previous names |
2008 - 08/2012 CFL Patron |
|
Type |
General cargo ship - Heavycargo - Equipped for carriage of containers - Box Sid - Singledecker |
|
IMO-number |
9376464 |
|
Call sign |
PHNP |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
Previous flags |
03/2008 - 06/2016 the Netherlands, Groningen - Call sign: PHNP |
|
GT |
4.106 t |
|
DWT |
Summer: 6.529 t |
|
DWCC |
Summer: 6.300 t Winter: 6.200 t |
|
NT |
1.747 t |
|
Light ship |
1.685 t |
|
Number of 20ft containers |
In hold: 144 On deck: 122 Total: 266 |
|
Length |
118,90 m overall 111,69 m between perpendiculars |
|
Breadth |
13,35 m moulded |
|
Draught |
Summer: 6,08 m |
|
Air draft keel to mast |
24,30 m |
|
Freeboard |
3.030 mm |
|
Depth |
9,10 m |
|
Speed |
12,0 knots |
|
Built |
2008 |
|
Keel laid |
01/12/2005 |
|
Launch date |
15/02/2008 |
|
Date of completion |
14/03/2008 |
|
Builder |
Scheepswerf Peters B.V. Kampen The Netherlands |
|
Yard number |
813 |
|
Hull material |
Steel |
|
Movable bulkheads |
1x In hold 2 (8 Positions) |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 6L26 - 4 stroke single acting 6 cylinder 260 x 320 mm combustion engine 2.040 kW / 2.772 hp at 1.000 rpm Builder: Wärtsilä, Trieste - Italy |
|
Propellers |
1x Screw propeller controllable pitch |
|
Shaft generator |
1x 350 kVA - 280 kW |
|
Generators |
2x AGCO Sisu Power 634 main diesel generatorsets each 175 kVA - 140 kW - 204 hp |
|
Emergency generator |
1x AGCO Sisu Power 420 diesel generatorset 77 kVA - 62 kW - 102 hp |
|
Bow thruster |
1x 280 kW |
|
Number of holds |
2 Hold 1: 18,70 x 11,20 x 9,00 m height Hold 2: 59,90 x 11,20 x 9,00 m height |
|
Cargo hold capacity |
Grain/Bale: 278.703 ft³ - 7.928 m³ |
|
Number of hatches |
2 Hatch 1: 18,70 x 11,20 m Hatch 2: 59,90 x 11,20 m |
|
Pontoon hatch covers |
13 |
|
Max. permitted loads |
Tanktop: 15,0t/m² Hatch cover: 1,75 t/m² |
|
Tank capacities |
Fuel oil: 431,91 m³ Ballast: 2.378 m³ |
|
Anchor equipment |
Length: 467,50 m Diameter: 38 mm |
|
Lifting equipment |
1x Gantry crane for pontoons |
|
Cargo gear |
Gearless |
|
Manager |
Vertom Bereederungs GmbH & Co. KG Borgwardring 80 26802, Niedersachsen Germany |
|
Previous managers |
03/2008 - 08/2012 Saltra Chartering & Agencies B.V., Rotterdam - The Netherlands 08/2012 Vertom Scheepvaart- en Handelmaatschappij B.V., Rotterdam - The Netherlands |
|
Operator |
Vertom |
|
Previous names & owners |
03/2008 - 08/2012 CFL Patron - B.V. Scheepvaartonderneming CFL Patron, Groningen - The Netherlands |
|
Registered owner |
B.V. Scheepvaartonderneming CFL Patron Groningen The Netherlands |
|
Latest data adjustment |
01 August 2020 |
