Westerschelde 25 May 2015 |
 |
 |
 |
 |
|||
| Westerschelde 25/05/15 | Westerschelde 25/05/15 | Westerschelde 07/04/16 | Antwerpen 09/09/16 | |||
|
Name |
BBC PERU |
|
Previous names |
|
|
Type |
General cargo ship - Multi-purpose tweendecker Strengthened for heavy cargoes - Equipped for the carriage of containers - Equipped for the carriage of dangerous goods |
|
IMO-number |
9549592 |
|
Call sign |
V2QM5 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
9.750 |
|
DWT |
Summer: 13.537 t |
|
NT |
4.550 |
|
Number of 20ft containers |
712 |
|
Reefer plugs |
80 |
|
Length |
146,14 m overall 136,99 m between perpendiculars |
|
Breadth |
21,10 m moulded |
|
Draught |
Summer: 8,25 m |
|
Height above keel |
39,71 m |
|
Freeboard |
2.913 mm |
|
Depth |
11,45 m to main deck |
|
Speed |
Max: 15,00 knots Service: 13,00 knots Economic: 12,0 knots |
|
Built |
2012 |
|
Keel laid |
26/03/2011 |
|
Launch date |
24/09/2012 |
|
Date of completion |
07/12/2012 |
|
Builder casco |
Damen Yichang SY Yichang China Yard number: 567504 |
|
Builder completion |
Damen Shipweerf BV Gorinchem The Netherlands |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M43C - 4 stoke 6 cylinder 430 x 610 mm combustion engine 6.079 kW / 8.265 hp at 500 rpm Builder: Caterpillar Motoren GmbH & Co. KG, Rostocj - Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 121,0 rpm 4 Blades- Diameter: 4.950 mm |
|
Boilers |
1x CHO 1,00 m² / 13,0 bar 1x CHR Aalborg Industries 172,00 m² / 9,9 bar |
|
Shaft generator |
1x 1.148 kW |
|
Generators |
3x Caterpillar C18 main diesel generatorsets each 575 kVA - 460 kW - 668 hp |
|
Emergency generator |
1x Caterpillar C9 diesel generatorset 188 kVA |
|
Bow thruster |
1x Controllable pitch propeller 730 kW - 4 blades |
|
Number of holds |
2 Hold 1: 26,93 x 15,80/10,48 m Hold 2: 69,82 x 15,80 m |
|
Cargo hold capacity |
Hold 1: 4.005 m³ / 141.435 ft³ Hold 2: 13.252 m³ / 467.990 ft³ Total: 17.257 m³ / 609.425 ft³ |
|
Number of hatches |
2 |
|
Hatch type |
Hydraulic multi-folding |
|
Floor space under deck |
Under deck: 2.752 m² / 29.622 ft² On deck: 1.540 m² / 16.576 ft² |
|
Deck strengths |
Tanktop: 18,0 t/m² Tweendeck hold 1: 5,0 t/m² Hatchcover: 2,4 t/m² |
|
Tank capacities |
HFO (RMG 35): 731 m³ MGO (DMA): 91 m³ Lubrication oil: 38 m³ Dirty oil: 34 m³ Sludge: 17 m³ Separator water: 39 m³ Potable water: 121 m³ Ballast Water: 6.371 m³ |
|
Anchor equipment |
Length: 550,00 m Diameter: 54 mm |
|
Lifting equipment |
1x Deck crane for free fall boat, rescue boat and life raft |
|
Cargo gear |
2x Mac Gregor - Hägglund hydraulic deck cranes situated portside - SWL: 80 t each 160 t capacity combined |
|
Accommodation |
For a crew of 14 persons and 4 spare with heating, ventilation and air-conditioning |
|
Commercial manager |
HS Bereederungs Gmbh & Co KG Thyssenstrasse 16 49733 Haren (Ems) Germany |
|
ISM manager |
HS Service Gmbh & Co KG Thyssenstrasse 16 49733 Haren (Ems) Germany |
|
Operator |
BBC Chartering Leer Germany |
|
Registered owner |
HS Schiffahrts UG (haftungsbeschraenkt) & Co. KG MS ''Thekla'' c/o HS Bereederungs GmbH & Co KG Thyssenstrasse 16 49733, Haren (Ems) Germany |
|
Previous names & owners |
12/2012 - 11/2013 Thorco Chili - Eckhoff Reederei, Jork - Germany |
|
Latest data adjustment |
06 February 2026 |
