Westerschelde 03 February 2016 |
 |
| Westerschelde 03/02/16 |
|
Name |
TTM DRAGON |
|
Type |
Bulk carrier - Strengthened for heavy cargo loading |
|
IMO-number |
9478561 |
|
Call sign |
3EWE6 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
31.532 t registered |
|
DWT |
Summer: 55.947 t |
|
NT |
18.765 t registered |
|
Light ship |
9.931 t |
|
Length |
190,00 m overall |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 12,73 m |
|
Moulded L x B x D |
185,00 x 32,26 x 18,10 m |
|
Registered L x B x D |
186,48 x 32,26 x 18,10 m |
|
Freeboard |
5.427 mm |
|
Depth |
18,10 m moulded |
|
Speed |
15,4 knots |
|
Built |
2010 |
|
Keel laid |
07.12.2009 |
|
Launch date |
19.02.2010 |
|
Date of completion |
21.05.2010 |
|
Builder |
IHI Marine United Inc., Yokohama Shipyard Japan |
|
Yard number |
3263 |
|
Hull material |
Steel |
|
Main engine |
1x 2 stroke single acting 6 cylinder 500 x 2.050 mm diesel engine 8.890 kW at 116,0 rpm Manufacturer: Diesel United, Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 490 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 6,9 bar Evaporation: 2,49 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
4x Generators - 1.711 kVA |
|
Cargo hold capacity |
Bale: 67.062 m³ Grain: 72.062 m³ |
|
Manager |
Ta Tong Marine Co., Ltd. |
|
Registered owner |
Ocean Dragon Maritime S.A. |
|
Latest data adjustment |
19 February 2016 |
