Antwerpen 15 May 2014 |
 |
 |
|
| Antwerpen 14/05/14 | Antwerpen 14/05/14 |
|
Name |
MARTHA |
|
Previous names |
Launch as: 2008 Martha 2008 - 2011 Emilie K 2011 - 2016 Martha 2016 - 2019 ASCL Michelle |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
9373333 |
|
Call sign |
V2DH2 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
3.642 t |
|
DWT |
Summer: 4.464,1 t |
|
DWCC |
4.000 t |
|
NT |
1.790 t |
|
Displacement |
6.763 t |
|
Number of 20ft containers |
In hold: 120 On deck: 132 Total: 252 |
|
Length |
100,71 m overall 95,20 m between perpendiculars |
|
Breadth |
15,43 m extreme 15,20 m moulded |
|
Draught |
Summer: 5,62 m |
|
Keel to mast end |
28,85 m |
|
Depth |
7,30 m moulded |
|
Speed |
12,5 knots |
|
Built |
2008 |
|
Keel laid |
29/12/2004 |
|
Launch date |
20/11/2007 |
|
Date of completion |
25/03/2008 |
|
Builder |
Shipyard Rousse JSC Rousse Bulgaria |
|
Yard number |
876 |
|
Hull material |
shipbuilding steel (standard) |
|
Hull type |
Single hull partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
5 |
|
Number of decks |
1 |
|
Main engine |
1x MaK 8M25 - 4 stroke 8 cylinder 255 x 400 mm combustion engine engine 2.400 kW / 3.260 at 750 rpm Builder: Caterpillar Motoren GmbH & Co. |
|
Propellers |
1x Controllable pitch propeller - aft at 185 rpm |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated - 6,0 bar Heating Surface: 53,0 m² 1x Auxiliary boiler, oil/gas fired type - 6,0 bar Heating Surface: 53,0 m² |
|
Electric Installations |
2x Plant 400/ 230 V - 362 kVA 1x Plant 400 V - 550 kVA 1x Plant 400 V - 112,5 kVA 1x Plant 24 V - 145 Ah 1x Plant 24 V - 145 Ah 1x Plant 24 V - 145 Ah 1x Plant 24 V - 160 Ah |
|
Shaft generator |
1x 550 kVA |
|
Generators |
2x MAN D2876 LE301 diesel generatorsets each 362 kVA Builder: MAN Truck & Bus AG |
|
Emergency generator |
1x MAN D2866 E diesel generatorset 112,5 kVA Builder: MAN Truck & Bus AG |
|
Batteries |
2x Batteries for automation each 160 Ah 1x Battery for UPS radio 145 Ah 1x Battery for automation 145 Ah 1x Battery for start emergency engine 145 Ah |
|
Compressed air receivers |
2x Receivers, each 250 litres - 30,0 bar 1x Receiver 125 litres - 30,0 bar 1x Receiver 30 litres - 30,0 bar 1x Receiver 10 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster 220 kW |
|
Number of holds |
2 Hold 1: 31,40 x 12,78 x 8,33 m Hold 2: 31,85 x 12,78 x 8,33 m |
|
Cargo hold capacity |
Grain: 6.457 m³ / 230.000 ft³ |
|
Number of hatches |
2 Hatch 1: 27,60 x 13,10 m Hatch 2: 32,20 x 13,10 m |
|
Floor space |
Hold floor: 700 m² Deck floor: 760 m² |
|
Max permitted loads |
Tanktop: 15,0 t/m² Tween deck pontoons: 2,0 t/m² Hatch covers: 1,67 t/m² |
|
Tank capacities |
Heavy fuel oil: 317,0 m³ Marine gas oil: 48,0 m³ Lub oil: 7,0 m³ Fresh water: 49,0 m³ Ballast water: 2.325 m³ |
|
Anchor equipment |
3x Anchors weight each 2.460 kg Length: 467,50 m Diameter: 38 mm |
|
Cargo gear |
2x Deck cranes - SWL each 60,0 t Combination SWL 120 t |
|
Crew size |
12 |
|
Cargo gear |
2x NMF Cranes - SWL 60,0 t each |
|
Manager |
Schiffahrtskontor Baltik GmbH & Co. KG Hafenstrasse 6B 26789 Leer Germany |
|
Registered owner |
MS "MARTHA" Schiffahrtsgesellschaft mbH & Co. KG Hafenstrasse 6B 26789 Leer Germany |
|
Latest data adjustment |
07 May 2022 |
