Westerschelde 17 November 2015 |
 |
 |
 |
||
| Westerschelde 17/11/15 | Humber River, UK 13/07/18 | Westerschelde 27/03/17 | ||
|
Name |
ANITA |
|
Previous names |
10/2013 - 01/2014 Union Bronze |
|
Type |
General cargo ship - Container ship - Strength bottom Gearless box shaped single decker |
|
IMO-number |
9479577 |
|
Call sign |
PBAV |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
GT |
1.767 t |
|
DWT |
Summer/winter: 2.572 t |
|
NT |
927 t |
|
Number of 20ft containers |
In hold: 36 On deck: 18 Total: 54 |
|
Length |
87,50 m overall 84,24 m between perpendiculars |
|
Breadth |
11,30 m moulded |
|
Draught |
4,15 m |
|
Air draft |
9,00 m keel mast end 6,60 m mast down |
|
Freeboard |
1.262 mm |
|
Depth |
4,15 m moulded |
|
Speed |
11,2 knots |
|
Built |
2013 |
|
Launch date |
14/06/2010 |
|
Date of completion |
30/12/2013 |
|
Builder casco |
České Loděnice A.S. Křešice Czech Republic |
|
Builder completion |
Damen Shipyard Bergum Bergum The Netherlands |
|
Yard number |
9380 |
|
Hull material |
Steel |
|
Watertight compartments |
5 |
|
Movable bulkhead |
2x Grain bulkheads - 7 positions |
|
Continuous decks |
1 |
|
Main engine |
1x ABC 6MDZC - 4 stroke single acting 6 cylinder 256 x 310 mm combustion engine 1.104 kW / 1.500 bhp at 800 rpm Built: 2009 Builder: Anglo Belgian Corporation NV Wiedauwkaai 43 9000 Gent Belgium |
|
Propelling system |
1x Screw propeller solid - aft at 260 rpm |
|
Generators |
2x Sisu 74CTAG - 6cylinder 108 x 134 mm diesel engine 182 kW at 1.500 rpm connected with generators 137 kVA each |
|
Emergency generator |
1x Sisu 49DTG - 4 cylinder 108 x 134 mm diesel engine 74 kW at 1.500 rpm connected with generator 71 kVA |
|
Bow thruster |
1x 275 kW |
|
Number of holds |
1 55,7 x 9,30 x 6,40 m |
|
Total capacity of holds |
3.460,66 m³ / 121.000 ft³ |
|
Hatches |
1 55,7 x 9,30 m |
|
Pontoon hatch covers |
9 |
|
Max. permitted loads |
Tank top: 15,0 t/m² Hatch covers: 1,6 t/m² |
|
Tank capacities |
Fuel oil: 147,6 m³ |
|
Lifting equipment |
1x Gantry crane for pontoons |
|
Manager |
Vertom Scheepvaart- en Handelmaatschappij B.V. Rotterdam The Netherlands |
|
Registered owner |
Vertom UCS m.v. Anita B.V. Rotterdam The Netherlands |
|
Previous owners |
12/2013 - 01/2014 Antje G Shipping B.V., Wedde - The Netherlands |
|
Remarks |
Hydraulic lowerable bridge |
|
Latest data adjustment |
26 July 2020 |
