Name |
HATHOR |
|
Type |
Multi-purpose general cargo - Strengthened for heavy cargo |
|
IMO-number |
9373280 |
|
Call sign |
PHIY |
|
Flag |
The Netherlands |
|
Port of registry |
Midwolda |
|
GT |
2.545 t |
|
DWT |
Summer: 3.850 t |
|
DWCC |
Summer: 3.650 t Winter: 3.500 t |
|
NT |
1.460 t |
|
Length |
88,60 m overall 84,99 m between perpendiculars |
|
Breadth |
12,52 m moulded |
|
Draught |
Max.: 5,42 m |
|
Air draft |
21,50 m |
|
Depth |
7,00 m moulded |
|
Speed |
12,3 knots |
|
Built |
2007 |
|
Keel laid |
14/06/2006 |
|
Delivery date |
12/04/2007 |
|
Builder casco |
Brodogradilište “Sava” Mitrovica Serbia |
|
Builder completion |
Damen Shipyard Bergum Bergum The Netherlands |
|
Yard number |
9368 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Movable bulkhead |
2 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M20C - 4 stroke single acting 8 cylinder 200 x 300 mm combustion engine 1.520 kW at 1.000 rpm Starter type: Compressed air Builder: M.A.K. Caterpillar Motoren G.m.b.H., Kiel - Germany |
|
Gearbox |
1x Reintjes LAF-1563L - Reduction: 4,429:1 |
|
Propellers |
1x Controllable pitch propeller - aft at 235 rpm Diameter: 2.600 mm - 4 blades |
|
Electric installations |
1x Plant 400/230 Volt - 175 kVA 1x Plant 400/230 Volt - 345 kVA 1x Plant 400/230 Volt - 77 kVA |
|
Shaft generator |
1x 345 kVA |
|
Generators |
1x Sisu 634-DSBIG - 6 cylinder 108 x 134 mm diesel engine 140 kW at 1.500 rpm connected with generator 175 kVA Built: 2006 |
|
Emergency generator |
1x Sisu 420-DSRG - 4 cylinder 108 x 120 mm diesel engine 70 kW at 1.500 rpm connected with generator 77 kVA Built: 2006 |
|
Bow thruster |
1x Veth-Jet 2-K-1200 - 220 KW, forward |
|
Number of holds |
1 Dimensions: 62,50 x 10,12 x 8,40 m |
|
Cargo hold capacity |
Grain & Bale: 185.338 ft³ / 5.250 m³ |
|
Hold ventilation |
6x Air-changes/h |
|
Number of hatches |
1 Dimensions: 62,50 x 10,12 m |
|
Hatch type |
Pontoon |
|
Max. permitted loads |
Tanktop: 15,0 t/m² Deck: 1,6 t/m² |
|
Tank capacities |
Ballast water: 1.340 m³ Potable water: 55,0 m³ Fuel: 211,9 m³ Lub oil: 8,6 m³ Dirty oil: 4,0 m³ Sewage: 12,0 m³ Sludge: 4,0 m³ |
|
Anchor equipment |
2 Length: 193,00 m Weight: 1.350 kg each |
|
Lifting equipment |
1x Gantry deck crane - SWL 13,5 t |
|
Manager |
Amasus Shipping B.V. 9930 AG Delfzijl The Netherlands |
|
Previous managers |
04/2007 - 10/2014 Hunze Lloyd B.V., Midwolda - The Netherlands 10/2004 - 11/2015 Drenth Ship Consult, Farmsum - The Netherlands |
|
Owner |
Hathor Beheer B.V. Midwolda The Netherlands |
|
Latest data adjustment |
20 August 2020 |
