Antwerpen 25 May 2015 |
 |
 |
|
| Antwerpen 25/05/15 | Antwerpen 25/05/15 |
|
Name |
HAPPY SKY |
|
Type |
General cargo ship - heavy load/lift - strengthened for heavy cargoes |
|
IMO-number |
9457220 |
|
Call sign |
PCCH |
|
Flag |
The Netherlands |
|
Port of registry |
Amsterdam |
|
GT |
15.989 t |
|
DWT |
17.775 t inc. tween deck hatch covers, pilars |
|
Number of 20ft containers |
1.237 |
|
Length |
154,80 m overall 145,80 m between perpendiculars |
|
Breadth |
26,50 m moulded |
|
Draught |
Summer: 9,50 m |
|
Speed |
17,0 knots Service: 15,0 knots |
|
Built |
2013 |
|
Launch date |
01.09.2011 |
|
Date of completion |
04.03.2013 |
|
Builder |
Larsen & Toubro Ltd. |
|
Yard number |
81007 |
|
Hull material |
Steel |
|
Main engine |
1x Wärtsilä 8L46C - 4 stroke single acting 8 cylinder 460 x 580 mm diesel engine 8,775 kW / 11.934 bhp |
|
Propellers |
1 |
|
Bow thruster |
1x 1.000 kW |
|
Cargo hold capacity |
Grain/Bale 20.561 m³ 17,068 m³ if tweendeck installed |
|
Heights |
Heights adjustable in steps of 50 cm: 12,50 m with no tween deck Minimum height: 2,47 m Maximum height: 7,97 m |
|
Hatch openings |
Weather deck: 96,00 x 17,70 m Tween deck: 92,00 x 17,70 m |
|
Allowable loads |
Weather deck hatch covers: 4,0 t/m², with pillars: 12,5 t/m² Tween deck hatch covers: 4,0 t/m², with pillars: 12,5 t/m² Tank top: 20,0 t/m² |
|
Floor space |
Weather deck: 1.760 m² Tween deck: 1.742 m² Tank top: 1.530 m² |
|
Cargo gear |
2x Huisman cranes - SWL 900 t each - Situated on starboard side Trolley - SWL 37,5 t |
|
Crew |
19 |
|
Manager |
Biglift Shipping B.V. (Spliethoff's Bevrachtingskantoor group) The Netherlands |
|
Operator |
BigLift |
|
Owner |
Biglift Shipping |
|
Registered owner |
C.V. Scheepvaartonderneming Happy Sky |
|
Latest data adjustment |
24 July 2015 |
