Terneuzen, The Netherlands 04 September 2014 |
 |
| Terneuzen 04/09/14 |
|
Name |
CLEMENTINE |
|
Type |
Bulk carriers - Geared Supramax |
|
IMO-number |
9266205 |
|
Call sign |
MEWJ2 |
|
Flag |
United Kingdom |
|
Port of registry |
London |
|
GT |
27.985 t |
|
DWT |
Summer: 50.238 t |
|
NT |
16.631 t |
|
Length |
189,80 m overall |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 11,93 m |
|
Moulded L x B x D |
181,00 x 32,26 x 16,90 m |
|
Registered L x B x D |
181,90 x 32,26 x 16,90 m |
|
Freeboard |
5.018 mm |
|
Depth |
16,90 m moulded |
|
Speed |
Service: 14,5 knots Max.: 16,4 knots |
|
Built |
2004 |
|
Keel laid |
26.01.2004 |
|
Launch date |
08.04.2004 |
|
Date of completion |
24.06.2044 |
|
Builder |
Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works |
|
Yard number |
1576 |
|
Hull material |
Steel |
|
Main engine |
1x Mitsui MAN B&W 6S50MCC - 2 stroke single acting 6 cylinder 500 x 2.000 mm diesel engine - 8.090 kW / 10.999 hp at 127,0 rpm Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works - Japan |
|
Propeller shaft |
1x Oil lubrication haft with monitoring device Diameter: 480 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 6,9 bar Evaporation: 2,51 t/h Manufacturer: Osaka Boiler Mfg., Co., Ltd. |
|
Generators |
4x Generators - 1.900 kVA |
|
Number of holds |
5 Hold 1: 28,16 x 6,40 m forward - 23,40 m aft |
|
Total hold capacity |
Grain: 63.198,3 m³ Bales: 60.712,7 m³ |
|
Number of hatches |
5 |
|
Tank top strengths |
No 1: 20,0 t/m² |
|
Tank capacities |
Fuel oil: 1.884 m² Fresh water: 336 m² Water ballast: 15.782 m³ |
|
Cargo gear |
4x JIN Cranes - SWL 30,0 t each Grabs: 4x 12,0 t each |
|
Manager |
British Marine Plc United Kingdom |
|
Registered owner |
Clementine Shipping Limited |
|
Latest data adjustment |
28 December 2014 |
